Teltonika TRB500000200 Model TRB500 Industrial 5G Gateway, Speeds of up to 1 Gbps, 1x Ethernet Port, Auto APN, 2X Configurable Inputs/Outputs, Aluminum Housing, AU PSU; Not for use in USA

Teltonika TRB500000200 Model TRB500 Industrial 5G Gateway, Speeds of up to 1 Gbps, 1x Ethernet Port, Auto APN, 2x Configurable Inputs/Outputs, Aluminum Housing, AU PSU; Not for use in USA
Key Features: - Ultra-high cellular speeds of up to 1 Gbps- Supports both architectures (SA & NSA) to leverage the 5G infrastructure- Single-digit latency for mission-critical applications- Reliable communication for high data throughput- One of the smallest 5G gateways available in the market- Backward compatible with 4G (LTE CAT 20) and 3G network technologies-
Package Includes: TRB500 Gateway, AU PSU, 4 x Mobile antennas (swivel, SMA male), Micro-USB cable ( 0.8 m), Ethernet cable, SIM adapter kit, and
Quick Start GuideSpecifications:
Mobile: -
Status: Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP Bytes sent/received, connected band, IMSI, ICCID-
Black/White list: Operator black/white list-
Band management: Band lock, Used band status display-
APN: Automatic-
Bridge: Direct connection (bridge) between mobile ISP and device on
LAN
Ethernet: -
LAN: 1 x RJ45 port, 10/100/1000
MbpNetwork: -
Authentication: Pre-shared key, digital certicates, X.
509 certicates- Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address lterMQTT
GATEWAY: -
Gateway: Allows sending commands and receiving data from MODBUS Master through the MQTT brokerSystem

Specifications

: -
CPU: Single core ARM Cortex A7, 1.5
GHz- RAM: 256 MB (128 MB available for userspace) -
FLASH storage: 512 MB (200 MB available for userspace)
Input/Output: -
Output control: HTTP POST/GET, Schedule-
Events: SMS, EMAIL
Physical

Specifications

: -
Casing: Aluminum- Dimensions (W x H x
D): 3.93 x 1.18 x 3.67 inches-
Weight: 0.5 pounds
