Meanwell RSP-75-12 Power Supply - 75W 12V 6.3A - Low Profile

Features:
Universal AC input / Full range
Built-in active PFC function
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
1U low profile 30mm
Remote ON-OFF control
100% full load burn-in test
LED indicator for power on
3 years warranty
General Specification (Please refer to images below for detailed datasheet)
AC input voltage range: 85~264VAC; 120~370VDC
AC inrush current (max. ): Cold start, 35A at 230VAC
Overload protection: 105%~135% Constant current limiting, auto-recovery
Over temperature protection: Shut down o/p voltage, re-power on to recover
Setup,
rise,
hold up time: 600ms, 30ms, 16ms at full load
Withstand voltage:
I/P-O/P: 3.75 kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5 kVAC
Working temperature: -25~+70ºC (refer to output derating curve)
Safety standards: UL60950-1, TUV EN60950-1, EN61558-1, EN61558-2-16, CCC GB4943 approved
EMC standards: EN55022 (CISPR22) Class B, EN61000-3-2, -3, GB9254 class B, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024
Connection: 5P/ 9.5 mm pitch terminal block
Dimension (LxWxH) (mm): 159x97x 30mm
Packing: 30pcs / 14.2 kg
