MeanWell LRS-200-24 Power Supply - 200W 24V

Features: No load power consumption < 0.5W for 150W; < 0.75W for 200W/350WAC input selectable by switchWithstand 300VAC surge input for 5 secondsUltra compact and 1U low profileWithstand 5G vibration testHigh operating temperature up to 70oCProtections: Short circuit / Overload / Over voltage / Over temp. Cooling by free air convection (150W/200W); forced air cooling by built-in DC fan (350W) Compliance to IEC/EN60335-1 (PD3) and IEC/EN61558-1, -2-16 for household appliances (150W) Operating altitude up to 5000 metersLED indicator for power onHigh efficiency, long life and high reliabilityLow cost3 years warrantyGeneral Specification (Please refer to images below for detailed datasheet)
AC input voltage range: 115 / 230VAC by switchAC inrush current (max. ): Cold start, 60A
at 230VACDC adjustment range: 10% by potentiometerOverload protection
Range: 110%~140%Overload protection
Type: Hiccup mode, auto-recoveryOver voltage protection
Range: 115%~145% rated output voltageOver voltage protection
Type: Shut down o/p voltage, re-power
on to recoverWithstand voltage:
I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5 kVAC
Working temperature: -25~+70C (refer to output derating curve)
Safety standards: UL60950-1
approvedEMC standards: Design refer to EN55022 class
AConnection: 9P/ 9.5 mm pitch terminal blockDimension (LxWxH): 215x 115x 30
