Mean Well MDR-60-12 AC to DC DIN-Rail Power Supply 12V 5 Amp 60W
- Primary output voltage (vdc): 12
- Output current (a): 5
- Maximum output power (w): 60
- Family: mdr-60
- Input voltage (vac): 85 to 264
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
60W DIN-RAIL SWITCHING POWER SUPPLY 12 Volts 5
Amps
Protections: Short-circuit, Overload, Overvoltage 100% Full load burn-in test Soft-start circuit, limiting AC surge current
Input Voltage: 85-264VAC 47-63Hz, or 120-370VDC
Input Current Full load: 1.8A (115V) / 1.0A (230V)
Size: 3.9 x 1.6" x 3.5"
Weight: 0.7 lbs. 3-year warranty For more 12 Volt power supplies.
Detailed
Output Voltage (VDC): 12
Output Current (A): 5 Maximum
Output Power (W): 60
Family: MDR-60
Input Voltage (VAC): 85 to 264
Input Frequency: 47 to 63
Maximum Input Current (A): 1.8 Output
Connector Type: Screw Terminal
Efficiency (%): 86
Operating Temperature-Min (Cell): -20
Operating Temperature-Max (Cell): 70
Length (inch): 1.57
Width (inch): 3.54
Height (inch): 3.94
Agency Approvals: UL/CUL/TUV/CB/CE
Color: White
Style: DIN".
Amps
Specifications
: Universal AC input rangeProtections: Short-circuit, Overload, Overvoltage 100% Full load burn-in test Soft-start circuit, limiting AC surge current
Input Voltage: 85-264VAC 47-63Hz, or 120-370VDC
Input Current Full load: 1.8A (115V) / 1.0A (230V)
Size: 3.9 x 1.6" x 3.5"
Weight: 0.7 lbs. 3-year warranty For more 12 Volt power supplies.
Detailed
Specifications
: PrimaryOutput Voltage (VDC): 12
Output Current (A): 5 Maximum
Output Power (W): 60
Family: MDR-60
Input Voltage (VAC): 85 to 264
Input Frequency: 47 to 63
Maximum Input Current (A): 1.8 Output
Connector Type: Screw Terminal
Efficiency (%): 86
Operating Temperature-Min (Cell): -20
Operating Temperature-Max (Cell): 70
Length (inch): 1.57
Width (inch): 3.54
Height (inch): 3.94
Agency Approvals: UL/CUL/TUV/CB/CE
Color: White
Style: DIN".
