KINDLY NOTICE: The expandable NVR supports up to 8 cameras, you can add 4 more cameras. Cameras will auto-pair with NVR, no need to hook any video cable between them. Plug power supplies of each camera and NVR into power outlets nearby, then images will appear on screen. NVR should be hook up into router with Ethernet cable if you need remote access. 1T surveillance HDD is already pre-installed for around 26 days of 4CH cameras' continuous recording. HDD will overwrite automatically when it's full. Please contact us if you need assistance for extending wifi range. If you need motion detection applications, please set them up properly by adjusting motion sensitivity, area and time to avoid false trigger such as plants blown by the wind. Audio and PTZ function are not supported. Please read the user's manual and test cameras' wifi signal before installation.
NVR Features: 1. 8CH 1080P NVR with 10.1" Monitor and 1T HDD Pre-installed 2. HI3520DV300 Processor and Embedded Linux Operating System
3. Support Video Preview/Recording/Playback/USB Backup
4. Support Android/IOS/PC Remote View
5.
Networking Protocol: UPNP, SMTP, PPPOE, DHCP etc.
6. Support 1sata * 4TB (Max) HDD 7. 1* HDMI interface, 2* USB interface
8.
Power Supply Input: DC12V-3A
Camera Features: 1.
Image Sensor: 1/4"Progressive Scan Sensor 2.
Resolution: 1280 x 960P 3.
Lens: 3.6 mm 4.
Day&Night: Auto / Color / BW 5.
Weatherproof: IP66 standard 6.
Power Supply Input: DC12V-1A
Packing list: * 1 x 8Ch 1080P NVR with 10.1" Monitor Pre-installed 1T HDD * 1 x 3.3 Feet Power Supply (12V-3A) for NVR * 4 x 960P IPC * 4 x 10 Feet Power Supply (12V-1A) for IPC * 4 x Screw Bag (for camera) * 4 x Cam Antenna * 1 x User manual * 1 x USB Mouse * 1 x 3.3 Feet Network Cable* 4 x Surveillance warning note
