1. 100% full power and stable current output, non-isolated module. 2. Waterproof level IP68 and anti-shock protection, Ultra compact size, light weight. 3. Industry grade DC 24V to DC 12V step-down converter, efficiency up to 95%. 4. Die-cast aluminum shell, epoxy potting, cooling by free air convection. 5.
Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circuit, auto-recovery when device is back to normal operating. 6.
Certificates: CE/RoHS, 1 year warranty, lifetime up to 100, 000 hours.
Specifications
: *
Input Rated Voltage: DC 24V*
Input Voltage Range: 30-60V
DC(Long time use: DC 32V-55V)*
Output voltage: DC12V 60A*
Output Rated Power: 720W*
Efficiency: 97% (half load); 95% (full load) *
Output Peak Power: 750W*
Voltage Regulation: Less Than 1%*
Load Regulation: Less Than 2%*
Ripple (full load test): Less Than 100mV*
No-load Current: 50mA-60mA*
Total Size: 180*127*63mm (L*W*H) *
Weight: 1650gPackage
included: 1 x DC 36V 48V to DC 12V 60A Voltage Converter
