DS18 G3600.6D 6-Channel Full-Range Class D Car Amplifier 3600 Watts Peak Power, 200W RMS x6 @4, 250W RMS x6 @2, 500W x3 Bridged @4 Adjustable Crossover, Bass Boost, Remote Level Control
- Massive Multi-Channel Power Unleash 3600W peak output with the DS18 G3600.6D! Delivers 200W RMS x6 @4, 250W RMS x6 @2, or 500W x3 bridged @4, perfect for powering an entire car audio system with precision and clarity
- Precision Audio Control Fine-tune your sound with variable high-pass, band-pass, and full-range crossovers. Adjustable bass boost up to 12dB @45Hz lets you shape your low-end exactly the way you want
- Superior Efficiency & Sound Quality Featuring 75% efficiency @4 and a signal-to-noise ratio >90dB, this digital Class D amplifier delivers clean, powerful sound with ultra-low distortion (THD 0.01%) and wide 20Hz20kHz response
- Full Protection Suite Designed to perform safely under pressure, with built-in thermal, overload, short circuit, DC output, voltage input, and clipping protections, ensuring long-term reliability and durability
- Compact & Versatile Design Matte black finish and slim 12.8" body for easy installation. Includes 4GA power input, remote level
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
PowerTotal Power (Peak): 3600WRMS Power @ 4: 6 x 200WRMS Power @ 2: 6 x 250WRMS Power @ 4
Bridge: 3 x 500WAudio
SpecificationsFrequency Response: 20Hz 20KHzSignal-to-Noise
Ratio: >90dBEfficiency @ 4: 75 %Damping
Factor: 75Input
Impedance: 22KChannel
Separation: 57dBTotal
Harmonic Distortion (THD): 0.01 %Low
Level Input Range: 0.25V 6VHigh
Level Input: NoSelectable
Crossover: Variable HPF / HPF-BPF-FULL (CH 5/6)Crossover
Filter Range:
HPF: 10250Hz /
LPF: 50250HzBass
Boost Range: 012dBBass
Boost Frequency: Fixed @ 45HzInfrasonic
Filter: N/APhase
Selector: NoFeaturesAmplifier
Class: Digital (Class D)
Amplifier Type: Full RangeNumber of
Channels: 6
ChannelsMinimum Impedance: 2 Stereo / 4
BridgeLED Indicators: Power / Protection / ClipPower
Input Terminal Size: 4GAFuse
Rating: 3 x 40ARemote
Level Control: YesCooling
Fan:
NoVoltmeter: NoThermal
Protection: YesOverload
Protection: YesDC
Output Protection: YesShort Circuit
Output Protection: YesVoltage
Input Protection: YesClipping
Protection: YesBody
Color / Finish: Matte
BlackMeasurementsOverall Length: 12.8" (325mm)
Overall Width: 4.72" (120mm)
Overall Height: 1.96" (50mm)
Heatsink Length: 10.9" (278mm) Gross
Weight (Single Unit): 2.2 kgExtra
FeaturesInput Selector: Yes (2CH / 4CH / 6CH)Compact Size for
Easy Installation: YesStable & Reliable Two or Four
Layer PCB Design: YesSurface Mount
Component Technology: YesQuality Control Verification using
Audio Precision Instruments: Yes
Bridge: 3 x 500WAudio
SpecificationsFrequency Response: 20Hz 20KHzSignal-to-Noise
Ratio: >90dBEfficiency @ 4: 75 %Damping
Factor: 75Input
Impedance: 22KChannel
Separation: 57dBTotal
Harmonic Distortion (THD): 0.01 %Low
Level Input Range: 0.25V 6VHigh
Level Input: NoSelectable
Crossover: Variable HPF / HPF-BPF-FULL (CH 5/6)Crossover
Filter Range:
HPF: 10250Hz /
LPF: 50250HzBass
Boost Range: 012dBBass
Boost Frequency: Fixed @ 45HzInfrasonic
Filter: N/APhase
Selector: NoFeaturesAmplifier
Class: Digital (Class D)
Amplifier Type: Full RangeNumber of
Channels: 6
ChannelsMinimum Impedance: 2 Stereo / 4
BridgeLED Indicators: Power / Protection / ClipPower
Input Terminal Size: 4GAFuse
Rating: 3 x 40ARemote
Level Control: YesCooling
Fan:
NoVoltmeter: NoThermal
Protection: YesOverload
Protection: YesDC
Output Protection: YesShort Circuit
Output Protection: YesVoltage
Input Protection: YesClipping
Protection: YesBody
Color / Finish: Matte
BlackMeasurementsOverall Length: 12.8" (325mm)
Overall Width: 4.72" (120mm)
Overall Height: 1.96" (50mm)
Heatsink Length: 10.9" (278mm) Gross
Weight (Single Unit): 2.2 kgExtra
FeaturesInput Selector: Yes (2CH / 4CH / 6CH)Compact Size for
Easy Installation: YesStable & Reliable Two or Four
Layer PCB Design: YesSurface Mount
Component Technology: YesQuality Control Verification using
Audio Precision Instruments: Yes
