CameraImage Sensor: 1/ 2.7" Progressive Scan CMOS
Signal System: PAL/NTSC
Min.
Illumination: 0.01 Lux @ (F 2.0, AGC ON), 0 Lux with
LightShutter time: 1/3 s to 1/100, 000
sSlow shutter:
SupportLens: 4 mm, Horizontal FOV 112, vertical FOV 61, diagonal FOV 134Lens
Mount: M12Day&
Night: AutoDigital
noise reduction: 3D DNR
Compression StandardVideo Compression: H. 265+/H. 265/H. 264+/H. 264/MJPEG
Video bit rate: 32Kbps~16MbpsImageMax.
Image Resolution: 3840 2160 @ 15fpsImage
Enhancement: BLC/3D DNR/HLC/ROI
Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browserROI: Support 1 fixed region for main stream and sub-stream separatelyNetworkNetwork
Storage: microSD/SDHC/SDXC card (512G), local storage and NAS (NFS, SMB/CIFS), ANR
General Function: One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filterInterfaceCommunication
Interface: 1 RJ45 10M / 100M
Ethernet interfaceReset Button: YesSmart
Feature-setBehavior Analysis: Line crossing detection, intrusion detection, unattended baggage detection, object removal detectionLine
Crossing Detection: Cross a pre-defined virtual lineIntrusion
Detection: Enter and loiter in a pre-defined virtual regionUnattended
Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materialsObject
Removal: Objects removed from the pre-defined region, such as the exhibits on display.
GeneralPower Supply: 12 VDC 25%, 5.5 mm coaxial power plug, PoE ( 802.3 af, class 3)Weather
Proof: IP67
