Cerwin Vega VCU84 600W 4-Channel Digital Amplifier with Control Knob

VCU84 - VEGA Series 4-Channel Full Range Class-D AmplifierCerwin-Vega Vega Series Amplifiers Compact Design, Monstrous PowerThe Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact package. Dont be deceived by their streamlined designthese amplifiers pack a punch with monstrous power output to drive your system to its fullest potential. Innovation Meets PowerUpdated High-Efficiency Full
Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency. Enhanced Power
IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition. Engineered for DurabilityConformal-Coated 4-Layer
PCB: Protected against moisture and environmental wear for long-lasting reliability.
Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.
Unmatched VersatilityRemote Turn-On Configurator (REM/DC/VOX): Simplifies integration with any audio system. Accepts Hi and
Lo-Level Inputs Up to 12V: Seamlessly connects to your existing setup, no matter the source.
Boosted RFI Rejection: Keeps your sound crystal-clear, free from interference. Compact Design, Big ImpactThe matching heatsink platform dimensions ensure a consistent, stylish look while optimizing thermal management for uninterrupted performance. Why Choose Vega? Whether youre a seasoned audio enthusiast or just starting to elevate your system, the Vega Series Amplifiers offer a balance of design, durability, and performance thats hard to beat. From pounding bass to crystal-clear highs, these amps are the powerhouse your system deserves. The Vega LegacyWith Cerwin-Vegas unmatched legacy of audio innovation and more than 65 years of expertise, the Vega Series Amplifiers continue to define whats possible in mobile sound systems. Compact. Powerful. Reliable. Elevate your audio experience with Vega Series Amplifiers.
SpecificationsPOWER RATINGFREQUENCY RESPONSE (HZ): 40HZ - 400HZRMS POWER PER CHANNEL 4 80W X 4RMS POWER PER CHANNEL 2 150W X 4RMS POWER PER 2 CHANNELS BRIDGED 4 300W X 2POWER SUPPLY
Power Supply: Full PWM
Power Supply Threshold: 10.0V - 17.0V (DC)
Idle Current: ( 0.7A )DISTORTIONTHD 4 (1KHz @4): 0.05 %S/N
Ratio (A weighted @1W): -85 dBAS/N
Ratio (A weighted @FP): - 101.1 dBAINPUT SENSITIVITY
Low
Input Level: 200mV- 10.0VH igh
Input Level: 200mV- 10.0VINPUT IMPEDANCE
Low
Input Level: 20 KHigh
Input Level: 20 KOUTPUT STAGE
Output Impedance: 0.018D amping
Factor (50Hz @ 4): >70Bandwidth
(-3dB): 10Hz-35KHzCROSSOVER (-12/-24 dB/Oct)Variable
High-Pass: 40Hz-400HzVariable
Low-Pass: 40Hz-400HzVariable
Sub-Sonic: FUSE
RATINGSATC: 40ADIMENSIONSL x W x
H: 8.8 x 4.02 x 1.4 ( 225.6 mm x 102mm x 36mm)FEATURES
Full Range Class D IR ChipsetDirectFET Power Mosfet Output StageSMD Technology on 4-Layer PCB BoardWater Resistant Conformal PCB Board Coating1-year Manufacturer's WarrantyMFR #: VCU84
