Specification: Sensor IMX322 Lens Size 1/ 2.9 inch Pixel Size 12.8X 11.6 mm image area 2000 (H) X1121 (V) approx. 2.24 M pixels Max. Resolution 1080P Compression format H264 /MJPEG / YUV2YUYV Resolution & frame H264320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fps MJPEG320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fps YUV320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 15 fps S/N Ratio 42dB Dynamic Range 86dB Sensitivity 5.0V /lux-sec@550nm Mini illumination 0. 01 lux Shutter Type Electronic rolling shutter / Frame exposure Connecting Port type USB 2.0 High Speed Free Drive Protocol USB Video ClassUVC Support OTG Protocol USB 2.0 OTG AEC Support AEB Support AGC Support Adjustable parameters Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White balance, Backlight Contrast, Exposure Digital audio High quality digital MIC, support single, dual channel LED board power connector Support 2P- 2.0 mm socket Power supply USB BUS POWER 4P- 2.0 mm socket Power supply DC5V Operating Voltage 140mA~190mA Working current -1070 Working temperature -2085 Board size /Weight 38X38mmCompatible 32X32mm/ about 30g Cable Standard 3M Operating system request Win7 Win8 Linux 2.6 or above Android 4.0 or above
