NV156FHM-T0E V8.0 40 pin IPS LCD in-Cell Touch Screen FHD 1920x1080 Glossy
- 1. [Quality Item] - 100% Original Brand New for HP Pavilion 15-EH LCD SCREEN Assembly Replacement Part.
- 2. [Compatibility] - Compatible for HP Pavilion 15-EH
- 3. [ Manufacturer Part Number(s) ] - NV156FHM-T0E
- 4. [Warranty] - F-HONG provide a 121-day warranty against any manufacturer defective such as dead-on arrival (DOA), lines, video failure, and backlight outage.
- 5.[Note] - Please check your model and compare the pictures for more details to ensure get the correct one! Please contact us if you have any question or problems!
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Panel Model: NV156FHM-T0E (BOE0947)
Panel Size: 15.6"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 1920 (RGB) 1080, FHD, 141PPI
Pixel Format: RGB Vertical Stripe
Display Area: 344.16 (W) 193.59 (H) mm
Outline Size: 350.66 (W) 216.15 (H) 3.35 (D) mm
Surface: Hard coating (3H)
Brightness: 250 cd/m (Typ. )
Contrast Ratio: 800:1 (Typ. )
(TM) Viewing Angle: 85/85/85/85 (Typ. )
(CR10) Display Mode: ADS, Normally Black, Transmissive
Best View on: Symmetry
Response Time: 16 (Typ.
)(Tr+Td) Display Colors: 262K 45% NTSC
Lamp Type: 10S4P WLED, 15K hours, With LED
Driver Frequency: 60Hz
Touch Screen: On-Cell Touch
Shape Style: Slim (PCBA Flat, T 3.2 mm)
Signal Interface: eDP (2 Lanes), eDP 1.2, HBR1 ( 2.7G /lane), 40 pins
Connector Input Voltage: 3.3V (Typ. )
Panel Size: 15.6"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 1920 (RGB) 1080, FHD, 141PPI
Pixel Format: RGB Vertical Stripe
Display Area: 344.16 (W) 193.59 (H) mm
Outline Size: 350.66 (W) 216.15 (H) 3.35 (D) mm
Surface: Hard coating (3H)
Brightness: 250 cd/m (Typ. )
Contrast Ratio: 800:1 (Typ. )
(TM) Viewing Angle: 85/85/85/85 (Typ. )
(CR10) Display Mode: ADS, Normally Black, Transmissive
Best View on: Symmetry
Response Time: 16 (Typ.
)(Tr+Td) Display Colors: 262K 45% NTSC
Lamp Type: 10S4P WLED, 15K hours, With LED
Driver Frequency: 60Hz
Touch Screen: On-Cell Touch
Shape Style: Slim (PCBA Flat, T 3.2 mm)
Signal Interface: eDP (2 Lanes), eDP 1.2, HBR1 ( 2.7G /lane), 40 pins
Connector Input Voltage: 3.3V (Typ. )
