Switch Power Supply 500W 36V Driver AC-DC Converter Transformer Adapter AC110/220V15% 36V DC Switching Power Supply, for LED, Display, Lighting, and Industrial Control Applications

Basic Overview: This compact, single-output enclosed power supply features a switchable input of 110VAC or 230VAC. With up to 85% efficiency and a built-in long-life cooling fan, it operates reliably within a temperature range of -10C to +50C under full load. Its ultra-low no-load power consumption ensures compliance with international energy standards. Additional features include resistance to 5G vibration and an integrated power-on LED indicator.
Output

Specifications

: The 500W power supply delivers a 36V DC output with a rated current of 13A. Ripple and noise levels are kept at 150mVp-p, and the voltage can be adjusted 5%, with an accuracy of 1.0 %. Both line and load regulation rates are 0.5 %.
Input

Specifications

: Input voltage ranges from 100-130VAC/190-264VAC (switch selectable) (switch set to 230VAC), with a frequency range of 47-63Hz. main size 21.5 cm X 11.3 cm X 5cm net weight 652g
Comprehensive Protections: Equipped with safeguards against overload, overvoltage, overheating, and short circuits. These protections are triggered by stopping or cutting output, with automatic recovery after a power reset.
Primary Applications: Ideal for industrial automation, control systems, electrical machinery, and electronic devices. Examples include LED light strips, billboards, communication devices, large displays, advertising light boxes, and automation equipment.
