Specification:
Sensor (1/ 3.2 ) IMX179
Picture format MJPEG/YUY2 /USB Protocal USB 2.0 HS/FS
Auto exposure AEC Support/Auto white blance AEB Support
Effective Pixels:
3264X2448/3200X2400/2592X1944/2048X1536/1600X1200/1280X960/1024X768/
800X600/640X480 (Other special size resolution is customized)
Performance:
3264X2448 MJPEG 15fps YUY2 2fps/3200X2400 MJPEG 20fps YUY2 3fps
2592X1944 MJPEG 15fps YUY2 3fps/2048X1536 MJPEG 20fps YUY2 3fps
1600X1200 MJPEG 20fps YUY2 10fps/1280X960 MJPEG 20fps YUY2 10fps
1024X768 MJPEG 30fps YUY2 10fps/800X600 MJPEG 30fps YUY2 30fps
640X480 MJPEG 30fps YUY2 30fp
Adjustable parameters Brightness/Contrast/Color saturation /Definition/Gamma/WB
Voltage DC 5V/current 150mA/work temperature DEGREES(-20~70)
Size: 38mm*38mm/32*32mm (other size cutomised)
Support OS "WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4. 8 or later, Operating
System Support: WinXP/Vista/Win7/Win8 Linux with UVCabove linux- 2.6. 26 MAC-OS X 10.4. 8 or later Wince with UVC Android 4.0 or above with UVC.
