5 Port 10/100Mpbs POE Switch 4 POE Port and 1 Uplink Ethernet Support Extend 250m 52V network switch

5 Port 10/100Mpbs POE Switch 4 POE Port and 1 Uplink Ethernet Support Extend 250m 52V network switch

Model number: TXE104

Hardware Specifications

Network Connector

5-port RJ45 for 10/100BASE-TX, auto MDI/MDIX

PoE Inject Port

4-port with 802.3af/at PoE injector function (Port 1 to Port 4)

LED Display

System:

Power (Green)

Per PoE port:

PoE (Red/Blue, Port 1 to Port 4)

LNK/ACT (Green, Port 1 to Port 5)

DIP Switch

Standard mode for 100M

Extend mode for 250m (Based on the cable category)

Switch Architecture

Store and Forward switch architecture

MAC Address Table

1K MAC address table with auto learning function

EST Protection

4KV

Switch Fabric

1Gbps

Switch Throughput

0.74Mpps @64bytes

Maximum Packet Size

1536bytes

Flow Control

Back pressure for half duplex. IEEE 802.3x pause frame for full duplex

Power Requirements

52V DC, 1.25A or 52V0.92A

Power Consumption

Max. 65watts,

Dimensions (W x D x H)

124*72*24 mm
