3pcs XL63020-5V Li Battery/USB Auto Boost Power Module Microcontroller Power Supply Low Ripple TPS63020 Solution
- Advanced Power Management The TPS63020 chip ensures power delivery with automatic switching between boost and buck modes, maintaining stable output from 1.8V to 5.5V. Whether your device needs a steady 3.3V at 1.3A, 4.2V at 1A, or 5V at 0.9A, this module delivers exceptional performance. With dual energy-saving modes, you can enjoy up to 90% efficiency during light loads, making it Suitable for modern gadgets that demand both speed and sustainability.; Compact Design for Space-Saving Designed with precision engineering, this USB auto-lift/drop power module measures just 17.4mm x 26.2mm, allowing for easy integration into tight spaces. Its compact size makes it Suitable for small electronics like smartwatches, fitness trackers, and IoT devices. By using vertical welding, it further optimizes space utilization without compromising functionality.; Low Ripple for Clean Power This module boasts an industry-leading low ripple of only 5mVpp thanks to its full ceramic capacitor design. It keeps interference far from sensitive components like ADC sensors, ensuring accurate readings every time. Whether you're powering a camera or a device, clean power is essentialand we deliver.; Effortless Customization Simply disconnect the default jumpers and solder the appropriate resistor based on our simple formula. For example, to achieve 4.0V, calculate R2 = (180K × (4.0×0.5 - 1)) - R1. Our user-friendly design allows for quick adjustments to meet your unique requirements.; Reliabl...
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Product description
Product core features: Core
solution: TI TPS63020 chip
Voltage conversion: automatic switching between boost and boost, covering the full discharge cycle of lithium batteries ( 1.8 - 5.5V input) Three outputs
Jumper switching: 3.3V ( 1.3A ) / 4.2V (1A) / 5V ( 0.9A ) Energy
Efficiency Management Dual-mode: conventional mode (dynamic response priority) + power saving mode (light load efficiency > 90%) Ripple Control Full Ceramic capacitor design, no-load ripple as low as 5mVpp (industry 1/6)
Version Parameter & Pin Definition: Only Version V 1.00
Size: 17.4 × 26.2 mm
Switching Frequency: 2.4MH z
Operating Temperature: -40°C~85°C
Pin Definition:
VIN: Input positive ( 1.8 - 5.5V ) Reverse connection is strictly prohibited!
PS: Shorted = Power saving mode Remove LED to reduce power consumption again
EN: Suspended = Enable, Low = Off Do not ground! Jumper pads Voltage selection (3V3/4V2/5V) Multiple simultaneous shorting prohibited! User pain point solution Battery voltage drop caused by equipment crash 1.8V continuous regulated output ( 3.7V 1.8V throughout the regulated) traditional DCDC interference sensor signal 15mV ripple + 2.4MH z high frequency away from the ADC sampling band small size equipment space constraints 17.4 mm × 26.2 mm + vertical welding to save space
Q1: Why does it consume power when no load?
Q2: How to output non-standard voltage such as 4.0V?
Q3: Input 5V output 3.3V is buck or boost? Electronic OK Wire & Solder Wire 8-Color Wrapping Wire Add to...
Product core features: Core
solution: TI TPS63020 chip
Voltage conversion: automatic switching between boost and boost, covering the full discharge cycle of lithium batteries ( 1.8 - 5.5V input) Three outputs
Jumper switching: 3.3V ( 1.3A ) / 4.2V (1A) / 5V ( 0.9A ) Energy
Efficiency Management Dual-mode: conventional mode (dynamic response priority) + power saving mode (light load efficiency > 90%) Ripple Control Full Ceramic capacitor design, no-load ripple as low as 5mVpp (industry 1/6)
Version Parameter & Pin Definition: Only Version V 1.00
Size: 17.4 × 26.2 mm
Switching Frequency: 2.4MH z
Operating Temperature: -40°C~85°C
Pin Definition:
VIN: Input positive ( 1.8 - 5.5V ) Reverse connection is strictly prohibited!
PS: Shorted = Power saving mode Remove LED to reduce power consumption again
EN: Suspended = Enable, Low = Off Do not ground! Jumper pads Voltage selection (3V3/4V2/5V) Multiple simultaneous shorting prohibited! User pain point solution Battery voltage drop caused by equipment crash 1.8V continuous regulated output ( 3.7V 1.8V throughout the regulated) traditional DCDC interference sensor signal 15mV ripple + 2.4MH z high frequency away from the ADC sampling band small size equipment space constraints 17.4 mm × 26.2 mm + vertical welding to save space
Q1: Why does it consume power when no load?
Q2: How to output non-standard voltage such as 4.0V?
Q3: Input 5V output 3.3V is buck or boost? Electronic OK Wire & Solder Wire 8-Color Wrapping Wire Add to...
