IP67 Boost Converter | 5V to 12V 10A 120W Step Up Power Module with Circuit Protection
- Advanced & Stable Technology: Features synchronous voltage stabilization and uses MOSFETs instead of diodes, ensuring Durability-Optimized, sufficient power, low heat, and significantly improved efficiency for reliable power supply.; High-Power & Efficient Conversion: This 120W DC-DC boost converter efficiently steps up voltage from 5V-11V to a stable 12V±0.25V, delivering up to 10A current with a high 96% efficiency, minimizing power loss and heat generation.; Comprehensive Safety Protections: Built-in safeguards include over-current, over-voltage, over-temperature, and short circuit protection, ensuring the safety and longevity of both the module and your connected devices.; Robust & Durable Construction: Sealed with silicone for an IP67 , , and anti-vibration rating. Made with FR-4 multilayer PCB and SMD components, it's built to withstand harsh operating conditions from -20 to 80.; Ready-to-Use Package: Includes one boost converter module (74x74x32mm) with pre-drilled mounting holes (65mm pitch). Note: New or old product type may be shipped randomly.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Features: Made of FR-4 multilayer PCB, resistor, capacitor, switch and MOS tube are all SMD components. Synchronous voltage stabilization technology, low heat, enough power and Durability-Optimized. It uses MOSFET to replace rectifier diode so greatly reduces power loss and improve efficiency of DC/DC converter. It supports over-current, over-voltage, over-temperature and short circuit protection. Sealed with silicone which is water, dust, anti-vibration and suitable for harsh conditions.
Voltage Range: 5V~11V
Output Voltage: 12V± 0.25V
Output Current: 10A.
Output Power: 120W Continuous
Output Power: 100W
Efficiency: 96%
Operating Temperature: -20~80
IP Rating: IP67
Size: 74*74*32mm/ 2.91 * 2.91 * 1.25"
Mounting Hole Pitch: 65mm/ 2.55"
Mounting Hole Diameter: 5mm/ 0.19
Package Includes: 1 x
Boost Converter Note: Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering..
Specifications
: InputVoltage Range: 5V~11V
Output Voltage: 12V± 0.25V
Output Current: 10A.
Output Power: 120W Continuous
Output Power: 100W
Efficiency: 96%
Operating Temperature: -20~80
IP Rating: IP67
Size: 74*74*32mm/ 2.91 * 2.91 * 1.25"
Mounting Hole Pitch: 65mm/ 2.55"
Mounting Hole Diameter: 5mm/ 0.19
Package Includes: 1 x
Boost Converter Note: Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering..
