Question 1

Can you put a cooler master hyper 212 inside it?

Accepted Answer

According to manufacturer specifications the case is 202mm wide and the hyper 212 is 159mm tall. I would guess it'd be a real tight squeeze when taking into account what the inner case frame, stanchions, motherboard socket and cpu take away from that. Minus the hyper 212's 159mm's it would leave you 43mm (1.64in) left so I'd guesstimate all the rest would take up an inch maybe a little more so real tight squeeze but it'll probably fit but just barely.

Question 2

How do you put the top fans in? Does the top piece come off?

Accepted Answer

Yes it does, I struggle with the same problem for a little while LOL. If you look on the inside of the case towards the back near the I/O shield there is a tiny Phillips head screw on both sides of the back of the case, remove those screws and slide lid forward towards the front and lift up. also, don't make the same mistake I did make sure you mount the fans on the top of the case not on the inside. So that they are pulling air through the lid, this is one of the most difficult cases to build in without an instruction manual even for someone who builds cases all the time I had issues with feeding my eight pin CPU cable and things like that through the very tiny holes that this case provides for cable management.

Question 3

When i look in specifications it says there is no side panel but on the picture their is so is there one?

Accepted Answer

Hello,

Thank you for contacting us in regards to your question.

The best way to confirm specs is actually by checking the manufacturer's website (that's where we get them). Click on the Specifications tab on the item page, and look in the Quick Info box on the bottom of the page. You'll find a link to the item on the manufacturer's own site with the most up-to-date details.

Thank you,
Newegg Support

Question 4

Will EATX fit?

Accepted Answer

Unless you take the time to do some modding by removing the optical and hard drive bays, then no.

Question 5

does it support a water radiator?

Accepted Answer

Yes. A 120mm in the front in push/pull. Although you might have to factor in video card length depending on the thickness of the radiator.  A thin 240mm radiator can fit in the top if you mount the fans outside of the case and under the top cover.

BASIC SPECIFICATION
EXTERNAL DRIVE BAYS:	1 x 5.25"
INTERNAL DRIVE BAYS:	3 X 3.5" or 2.5" H.D.
SYSTEM BOARD:	ATX/ MICRO ATX/ MINI ITX
EXPANSION SLOTS:	7 SLOTS
CARD READER:	SD, MICRO SD
I/O PORTS:	1 X USB3.0/2 X USB2.0 / 2 x HD AUDIO
DIMENSIONS:	503(D) X 202(W) X 529(H)mm

COOLING SYSTEM
FRONT:	2 X 120mm fan optional)
SIDE:	1 X 120mm fan optional)
BACK:	1 X 120mm fan
TOP:	2 X 120mm or 1 x 140mm fan (optional)
BOTTOM:	None

Brand	RAIDMAX
Model	ATX-366WB

Type	ATX / Micro ATX Mid Tower
Color	Black
With Power Supply	No
Motherboard Compatibility	Micro ATX / ATX / Mini-ITX
Side Panel	without Side Window

External 5.25" Drive Bays	1
Internal 3.5" Drive Bays	3 x 3.5" or 2.5" H.D.
Expansion Slots	7

RAIDMAX ATX-366WB Black ATX / Micro ATX Mid Tower Computer Case

TIGERSHARK

Learn more about the Raidmax ATX-366WB

Customer Reviews of the Raidmax ATX-366WB

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Dimensions & Weight
Dimensions	20.83" x 7.95" x 19.80"
Weight	10.48 lbs.

Item#: N82E16811156352
