GIGABYTE GA-8I865GME-775-RH-AS LGA 775 Intel 865G Micro ATX Intel Motherboard

(53) Write a Review

Intel 865G
Core 2 Extreme dual-core / Core 2 Duo / Pentium D / Pentium 4 / Celeron D
DDR 400

🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available

Overview

Specs

Reviews (53)

Any questions? Our AI beta will help you find out quickly.

Try me now

Model
Brand	GIGABYTE
Model	GA-8I865GME-775-RH-AS

Supported CPU
CPU Socket Type	LGA 775
CPU Type	Core 2 Extreme dual-core / Core 2 Duo / Pentium D / Pentium 4 / Celeron D
FSB	800/533 MHz
Supported CPU Technologies	Hyper-Threading Technology

Chipsets
Chipset	Intel 865G
South Bridge	Intel ICH5

Onboard Video
Onboard Video Chipset	Intel Extreme2 Graphics

Memory
Number of Memory Slots	2x184pin
Memory Standard	DDR 400
Maximum Memory Supported	2GB
Channel Supported	Dual Channel

Expansion Slots
AGP Slots	1 x AGP 4X / 8X
PCI Slots	3 x PCI Slots

Storage Devices
PATA	2 x ATA100 4 Dev. Max

Onboard Audio
Audio Chipset	Realtek ALC655
Audio Channels	6 Channels

Onboard LAN
LAN Chipset	EP82562G
Max LAN Speed	100Mbps

Rear Panel Ports
Back I/O Ports	2 x PS/2 / 4 x USB 2.0/1.1
PS/2	2
COM	1
LPT	1
Video Ports	D-Sub
USB 1.1/2.0	4 x USB 2.0
Audio Ports	3 Ports

Internal I/O Connectors
Onboard USB	4 x USB 2.0

Physical Spec
Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 8.4"
Power Pin	20 Pin

Packaging
Package Contents	GA-8I865GME-775-RH-AS Driver Disk User Manual Rear I/O Panel Shield IDE/PATA Cable FDD Cable SATA Cable

Additional Information
First Listed on Newegg	May 21, 2007
