GIGABYTE GA-8I915G-MF LGA 775 Intel 915G Micro ATX Intel Motherboard
- Intel 915G
- Pentium 4 Prescott / Celeron D
- DDR 400
Specs
Reviews (5)
Learn more about the GIGABYTE GA-8I915G-MF
| Brand | GIGABYTE |
|---|---|
| Model | GA-8I915G-MF |
| CPU Socket Type | LGA 775 |
|---|---|
| CPU Type | Pentium 4 Prescott / Celeron D |
| FSB | 800/533 MHz |
| Supported CPU Technologies | Hyper-Threading Technology |
| Chipset | Intel 915G |
|---|---|
| South Bridge | Intel ICH6 |
| Onboard Video Chipset | Intel GMA 900 |
|---|
| Number of Memory Slots | 4x184pin |
|---|---|
| Memory Standard | DDR 400 |
| Maximum Memory Supported | 4GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 1 x PCI Express x16 |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| PATA | 1 x ATA100 2 Dev. Max |
|---|---|
| SATA 1.5Gb/s | 4 x SATA 1.5 Gb/s |
| Audio Chipset | Realtek ALC880 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8110S |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x S/PDIF Coaxial Out / 2 x PS/2 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| LPT | 1 |
| Video Ports | D-Sub |
| USB 1.1/2.0 | 4 x USB 2.0 |
| S/PDIF Out | 1 x Coaxial |
| S/PDIF In | 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9.6" |
| Power Pin | 24 Pin |
| Date First Available | January 10, 2005 |
|---|
