GIGABYTE GA-EX58-UD3R-SLI LGA 1366 Intel X58 ATX Intel Motherboard
OUT OF STOCK.
- Intel X58
- Core i7 series
- DDR3 2000+/
Specs
Reviews
Learn more about the GIGABYTE GA-EX58-UD3R-SLI
| Brand | GIGABYTE |
|---|---|
| Model | GA-EX58-UD3R-SLI |
| CPU Socket Type | LGA 1366 |
|---|---|
| CPU Type | Core i7 series |
| FSB | QPI 6.4GT/S |
| Chipset | Intel X58 |
|---|---|
| South Bridge | Intel ICH10R |
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4×240pin |
|---|---|
| Memory Standard | DDR3 2000+/ |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual / Triple Channel |
| PCI Express 2.0 x16 | 2 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x4 | 1 x PCI Express x4 |
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| PATA | 1 x ATA100 2 Dev. Max |
|---|---|
| SATA 3Gb/s | 8 x SATA 3Gb/s |
| SATA RAID | 0/1/5/10/JBOD |
| Audio Chipset | Realtek ALC888 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111D |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
| PS/2 | 2 |
|---|---|
| USB 1.1/2.0 | 8 x USB 2.0 |
| IEEE 1394 | 2 x IEEE 1394a |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Date First Available | March 06, 2009 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Newegg.com's Standard Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-626-854-9338
- Support Website
- View other products from GIGABYTE
LOADING...
LOADING...

















Pros: Do not listen to the reviewer below... This is a near perfect motherboard as is the Gigabyte EX58-UD3R Non SLI Version. First of all if your using windows applications to do your overclocking, you shouldn't be overclocking in the first place! The system BIOS is the only place one should adjusting timings and or increasing front side bus frequencies IMO. If your overclocking from within Windows using 3rd party OC applications, your just asking for problems! The BIOS on this board is excellent for OC and Offers complete control over virtually everything! I have built 10 machines with this motherboard, not one single defect or RMA. This board will detect any amount of RAM right out of the box. This board will enable SLI, detect a second video card right out of the box. This board will pick up any HDD or device connected to it! RAID Setup is a breeze! If your looking for a High Quality, High Performance, Hassle Free Motherboard.. This is your Ticket!
Cons: Makes lousy Meatloaf!
Overall Review: I am a system builder of 12 years... this mobo comes w/ my Highest recommendation! You may find a board with a lot more bling and possibly more features, but you'll have a hard time finding one that is as reliable!
