GIGABYTE GA-H67M-D2 LGA 1155 Intel H67 SATA 6Gb/s Micro ATX Intel Motherboard
OUT OF STOCK.
- Intel H67
- Core i7 / i5 / i3 (LGA1155)
- DDR3 1333/ 1066/ 800
Specs
Reviews
Learn more about the GIGABYTE GA-H67M-D2
| Brand | GIGABYTE |
|---|---|
| Model | GA-H67M-D2 |
| CPU Socket Type | LGA 1155 |
|---|---|
| CPU Type | Core i7 / i5 / i3 (LGA1155) |
| Chipset | Intel H67 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 2×240pin |
|---|---|
| Memory Standard | DDR3 1333/ 1066/ 800 |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 (x16, x4) |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| SATA 3Gb/s | 4 x SATA 3Gb/s |
|---|---|
| SATA 6Gb/s | 2 x SATA 6Gb/s |
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC888B |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
| PS/2 | 2 |
|---|---|
| Video Ports | D-Sub + DVI |
| USB 1.1/2.0 | 8 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 8.39" |
| Power Pin | 24 Pin |
| Features | New 100% Hardware VRD 12 Compliant CPU Power Design DualBIOS - Unique Dual Hardware BIOS Protection 50,000 Hours Japanese Solid Capacitors On/Off Charge Technology Turbo XHD- Full Automatic RAID 0 Multi-display support with ATI CrossFireX Smart 6 – Smarter PC system Management AutoGreen- Greening your PC via Bluetooth cellphone ErP Lot 6 support |
|---|
| Date First Available | January 08, 2011 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Newegg.com's Standard Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-626-854-9338
- Support Website
- View other products from GIGABYTE
LOADING...
Pros: It has all the new bells and whistles. It has solid caps, the pins on the board are clearly labeled, it has 2 PCIe x16 slots (one is electrically x4). It runs rock solid and cool.
Cons: When I first got the board it had the F6 BIOS. When I upgraded it to the F9 BIOS and it gave me troubles. The problem is if you put the SATA into AHCI mode it freezes when trying to detect the IDE hard drives (even though there are no IDE ports on the motherboard.) I found if I reset the BIOS; and set all of the IDE hard drives to "None" rather than Auto, and then changed the SATA to run in AHCI mode it is fine. The copy of @Bios that comes on the CD cannot upgrade to the F9 BIOS, you need to download an updated version.
Overall Review: Overall it is a good board, besides the hiccup with the BIOS and detecting the hard drives it is great. I am sure they will fix the freeze up with the next BIOS release. And the workaround is easy and doesn't limit your functionality at all. These are all problems I expect with newly released product line. They need time to discover and work out all of the bugs.
