GIGABYTE GA-X79-UP4 LGA 2011 Intel X79 USB 3.0 ATX Intel Motherboard
Used - Good Product Type
- Intel X79
- Core i7 (LGA2011)
- DDR3 2133/1866
+
+
Specs
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the GIGABYTE GA-X79-UP4
| Brand | GIGABYTE |
|---|---|
| Model | GA-X79-UP4 |
| CPU Socket Type | LGA 2011 |
|---|---|
| CPU Type | Core i7 (LGA2011) / Xeon (LGA2011) |
| Chipset | Intel X79 |
|---|
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 8x240pin |
|---|---|
| Memory Standard | DDR3 2133/1866/1600/1333/1066 |
| Maximum Memory Supported | 64GB |
| Channel Supported | Quad Channel |
| PCI Express 3.0 x16 | 4 (x16, x16, x8, x8) |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 1 x PCI Slot |
| Serial ATA (SATA) | 6 x SATA 6Gb/s |
|---|---|
| SATA RAID | 2 x SATA 6Gb/s (SATA3 0/1) and 4 x SATA 3Gb/s (SATA2 2~5) Support for RAID 0, RAID 1, RAID 5, and RAID 10 4 x SATA 6Gb/s (SATA3 6~9) and 2 x eSATA 6Gb/s Support for RAID 0 and RAID 1 |
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| Max LAN Speed | 1Gbps |
|---|
| PS/2 | 1 x PS/2 keyboard/mouse port |
|---|---|
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 8 x USB 2.0 |
| eSATA | 2 x eSATA 6Gb/s |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 2 x USB 3.0 + 6 x USB 2.0 |
|---|---|
| Other Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 4 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x serial port header 1 x Clear CMOS jumper 1 x Trusted Platform Module (TPM) header |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | GIGABYTE 3D Power GIGABYTE 3D Power Utility GIGABYTE 3D BIOS GIGABYTE Ultra Durable 5 4 Channel Memory Architecture 4-way CrossFireX and 4-way SLI Support GIGABYTE 333 Onboard Acceleration GIGABYTE On/Off Charge |
|---|
| Date First Available | May 11, 2025 |
|---|
