Brand | MSI |
---|---|
Model | Z68A-G43 (B3) |
CPU Socket Type | LGA 1155 |
---|---|
CPU Type | Core i7 / i5 / i3 (LGA1155) |
Chipset | Intel Z68 |
---|
Onboard Video Chipset | Supported only by CPU with integrated graphic |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 1066 / 1333 / 1600* / 1866* / 2133*(OC) |
Maximum Memory Supported | 32GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 2 x PCI Express 2.0 x16 |
---|---|
PCI Express x1 | 2 x PCI Express x1 |
PCI Slots | 3 x PCI Slots |
Serial ATA (SATA) | 2 x SATA 6Gb/s |
---|---|
SATA RAID | 0/1/5/10 |
Audio Chipset | Realtek ALC887 |
---|---|
Audio Channels | 8 Channels |
LAN Chipset | Realtek 8111E |
---|---|
Max LAN Speed | 1Gbps |
Back I/O Ports | 2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1 |
---|---|
PS/2 | 2 |
Video Ports | D-Sub + DVI |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 6 Ports |
Onboard USB | 8 x USB 2.0 |
---|---|
Other Connectors | ATX 24-Pin power connector 4-pin ATX 12V power connector CPU x 1 / System x 3 FAN connectors Front panel audio connector Front panel connector 1 x chasis intrusion connector 1 x Clear CMOS jumper 1 x SPDIF-out connector 1 x TPM module connector 1 x Serial port connector 1 x Parallel port connector |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12" x 8.66" |
Power Pin | 24 Pin |
Features | Top quality & stability OC Genie II: Auto OC to boost performance in 1 sec ClickBIOS: Easy-to-use UEFI BIOS interface THX TruStudio PRO: deliver the fullest audio experience Support USB 3.0 & SATA 6Gb/s |
---|
Date First Available | July 29, 2011 |
---|
