ASUS P5E-VM HDMI <GREEN> LGA 775 Intel G35 HDMI Micro ATX Intel Motherboard
OUT OF STOCK.
- Intel G35
- Core 2 Quad / Core 2 Extreme / Core 2 Duo
- DDR2 800
Specs
Reviews
Learn more about the ASUS P5E-VM HDMI <GREEN>
| Brand | ASUS |
|---|---|
| Model | P5E-VM HDMI <GREEN> |
| CPU Socket Type | LGA 775 |
|---|---|
| CPU Type | Core 2 Quad / Core 2 Extreme / Core 2 Duo |
| FSB | 1333/1066 MHz |
| Chipset | Intel G35 |
|---|---|
| South Bridge | Intel ICH9R |
| Onboard Video Chipset | Intel GMA X3500 |
|---|
| Number of Memory Slots | 4×240pin |
|---|---|
| Memory Standard | DDR2 800 |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 1 x PCI Express x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 1 x PCI Slot |
| PATA | 1 x ATA100 2 Dev. Max |
|---|---|
| SATA 3Gb/s | 6 x SATA 3Gb/s |
| SATA RAID | 0/1/5/10 Matrix RAID |
| Audio Chipset | Realtek ALC883 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Atheros L1 |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
| PS/2 | 2 |
|---|---|
| Video Ports | D-Sub |
| HDMI | 1 x HDMI |
| USB 1.1/2.0 | 6 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394a |
| S/PDIF Out | 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9.6" |
| Power Pin | 24 Pin |
| Features | Support HD 1080P HDMI Connector onboard and Support Dual Display ASUS Splendid Technology ASUS Q-shield Elegant Black PCB of uATX mohterboard Precise Overclocking |
|---|
| Windows Vista | Certified for Windows Vista |
|---|
| Date First Available | December 07, 2007 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Newegg.com's Standard Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-510-739-3777
- Support Website
- View other products from ASUS
LOADING...
LOADING...

















Pros: HDMI onboard. DX10 support (I haven't tried this, reviews say there isn't any benefit at the moment). Lots of USB ports, and IEEE1394a. Supports newer 1333 MHz cpu, which are cheaper than equivalent 1066 chips now. mATX so you don't have to use a big ATX case for your HTPC. Onboard audio sounds pretty good over SPDIF. (No optical output, only coax.)
Cons: Only one PCI slot. When I was done migrating my components from the former mobo I had a stack of cards that no longer had a place to go. If you use a lot of add-on cards this might not be a good board for you. Integrated graphics don't seem to be all that great, even just for video use. (My Vista Exp Score is 3.8/3.9 for the graphics areas, which doesn't seem too bad but I've definitely had more problems with video than I did with the X1950PRO AGP card in the mobo this one replaced.) The video resolution is not (easily) customizable. From forums it seems to be possible to edit the registry, but I haven't tried it. A previous mobo upgrade ran from the same install of Vista, but this mobo wouldn't load vista at all so I had to do a format and reload.
Overall Review: I have zero gaming expectation for this system so I'd hoped the Intel IGP would be enough, but looks like I'm going to have to bite the bullet and get a new video card. The chipset is pretty new, so there might be some improvement with new drivers, but I don't have high hopes. Out of the box the IGP only showed about 4 resolutions. After about 20 minutes I figured out that I had to uncheck "only show supported modes" in the Vista graphics advanced settings, then I was able to see more modes in the Intel Graphics settings box. Still, the one closest to my tv's optimal setting is slightly overscanning. My ATI card had a utility to custom set the resolution right in CCC. BOTTOM LINE: Pretty good board that has a few bugs. Intel IGP falls just short for video (HD, divx, MS DVR) but fine for office work/internet.
