Brand | ASUS |
---|---|
Model | P5Q Pro Turbo |
CPU Socket Type | LGA 775 |
---|---|
CPU Type | Core 2 Quad / Core 2 Extreme / Core 2 Duo / Pentium dual-core / Celeron |
FSB | 1600/1333/1066/800 MHz |
Chipset | Intel P45 |
---|---|
South Bridge | Intel ICH10R |
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR2 1300/1200/1066/800/667 |
Maximum Memory Supported | 16GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 2 (support ATI CrossFireX technology at x8 link) PCIe x16_1 blue, PCIe x16_2 black (* black at max. x8 link) |
---|---|
PCI Express x1 | 3 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
PATA | 1 x ATA100 2 Dev. Max |
---|---|
SATA 3Gb/s | 5 + 2 |
SATA RAID | 0/1/5/10 Matrix RAID |
Audio Chipset | VIA VT1708S |
---|---|
Audio Channels | 8 Channels |
PS/2 | 2 |
---|---|
USB 1.1/2.0 | 6 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394a |
eSATA | 1 x eSATA 3Gb/s |
S/PDIF Out | 1 x Optical |
Audio Ports | 6 Ports |
Onboard USB | 6 x USB 2.0 |
---|---|
Onboard 1394 | 1 x 1394a |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12" x 9.6" ( 30.5 cm x 24.4 cm ) |
Power Pin | 24 Pin |
Date First Available | August 17, 2020 |
---|
