ASUS H97M-PLUS LGA 1150 Intel H97 HDMI SATA 6Gb/s USB 3.0 Micro ATX Intel Motherboard

Name: ASUS H97M-PLUS LGA 1150 Micro ATX Intel Motherboard
Brand: ASUS
SKU: N82E16813132119
Rating: 4 (14 reviews)

(14) Write a Review

ASUS 5X PROTECTION - DIGI+ VRM, Enhanced DRAM Overcurrent Protection, ESD Guards, High-Quality 5K-Hour Solid Capacitors, Stainless Steel Back I/O
M.2 onboard - Up to 10Gb/s data transfer speeds
Crystal Sound 2 - Flawless audio that makes you part of the game
UEFI BIOS - Most advanced options with fast response time
ASUS Home Cloud - Digital PC Hub Perfect for Sharing

🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available

Overview

Specs

Reviews (14)

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.com's Standard Return Policy. Read full return policy for details.

CPU Socket Type	LGA 1150
CPU Type	Celeron / Core i3 / Core i5 / Core i7 / Intel Core 4th Gen (LGA 1150) / Intel Core 5th Gen (LGA 1150) / Pentium

Number of Memory Slots	4x240pin
Memory Standard	DDR3 1600/ 1333
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	1 x PCI Express 3.0 x16
PCI Express 2.0 x16	1 (x4 mode)
PCI Slots	2 x PCI Slots

SATA 6Gb/s	6 x SATA 6Gb/s
M.2	1 x M.2
SATA RAID	0/1/5/10

Audio Chipset	Realtek ALC887
Audio Channels	8 Channels

ASUS H97M-PLUS LGA 1150 Intel H97 HDMI SATA 6Gb/s USB 3.0 Micro ATX Intel Motherboard

Learn more about the ASUS H97M-PLUS

Customer Reviews of the ASUS H97M-PLUS

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Back I/O Ports	1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 4 x USB 3.0
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x DVI-D 1 x VGA
HDMI	1 x HDMI
USB 3.0	4 x USB 3.0
USB 1.1/2.0	2 x USB 2.0
Audio Ports	6 Ports

Onboard USB	2 x USB 3.0 + 6 x USB 2.0
Other Connectors	1 x 4-pin CPU Fan connector 2 x 4-pin Chassis Fan connectors for 3-pin (DC mode) and 4-pin (PWM mode) coolers control 1 x Front panel audio connector (AAFP) 1 x S/PDIF out header 1 x parallel port connector(s) 1 x COM connector 1 x TPM connector 1 x 24-pin EATX Power connector 1 x 8-pin EATX 12V Power connector 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x MemOK! button 1 x GPU Boost switch

Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 8.8"
Power Pin	24 Pin

Model
Brand	ASUS
Model	H97M-PLUS

Onboard LAN
LAN Chipset	Intel I218-V
Max LAN Speed	1Gbps
