ECS H61H2-M4 (V1.0) LGA 1155 Intel H61 Micro ATX Intel Motherboard

Be the first to review this product...
  • Intel H61
  • 3rd/2nd-generation Core i7,i5,i3,Pentium,Celeron (LGA1155)
  • DDR3 1600/1333
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the ECS (EliteGroup) H61H2-M4 (V1.0)

Model
Brand ECS
Model H61H2-M4 (V1.0)
Supported CPU
CPU Socket Type LGA 1155
CPU Type 3rd/2nd-generation Core i7,i5,i3,Pentium,Celeron (LGA1155)
Chipsets
Chipset Intel H61
Onboard Video
Onboard Video Chipset Supported only by CPU with integrated graphic
Memory
Number of Memory Slots 2x240pin
Memory Standard DDR3 1600/1333
Maximum Memory Supported 16GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 3.0 x16 1 x PCI Express 3.0 x16
PCI Express x1 1 x PCI Express x1
Onboard Audio
Audio Chipset VIA VT1705
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Atheros AR8161
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 2 x PS/2 / 4 x USB 2.0/1.1
PS/2 1 x PS/2 Keyboard
1 x PS/2 mouse
Video Ports 1 x D-Sub (VGA)
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Other Connectors 1 x 24-pin ATx Power Supply connector
1 x 4-pin 12V Power connector
1 x 4-pin CPU_FAN connector
1 x 3-pin SYS_FAN connector
1 x Front panel audio header
1 x CLR_CMOS header
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 7.5" x 6.7"
Power Pin 24 Pin
Features
Features Applied Solid Capacitor for CPU VRM to ensure a longer lifespan for system

Microsoft Windows 8 Certified

Intel 22nm Multi-Core CPU support

Intel VRD 12 Ready

ECS Intelligent EZ Utility : eBLU, eDLU, eSF

Free Bundle: Norton Internet Security ,CyberLink PowerDVD, CyberLink PowerDirector 9,Muzee with trial version
Additional Information
First Listed on Newegg November 18, 2013

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 2 years
