Brand | DFI |
---|---|
Model | LP DK X58-T3eH6 |
CPU Socket Type | LGA 1366 |
---|---|
CPU Type | Core i7 (LGA1366) |
FSB | QPI 6.4GT/S |
Chipset | Intel X58 |
---|---|
South Bridge | Intel ICH10R |
Onboard Video Chipset | None |
---|
Number of Memory Slots | 6x240pin |
---|---|
Memory Standard | DDR3 1333 |
Maximum Memory Supported | 24GB |
Channel Supported | Triple Channel |
PCI Express 2.0 x16 | 3 x PCI Express 2.0 x16 |
---|---|
PCI Express x4 | 1 x PCI Express x4 |
PCI Slots | 2 x PCI Slots |
PATA | 1 x ATA100 2 Dev. Max |
---|---|
SATA 3Gb/s | 8 x SATA 3Gb/s |
SATA RAID | 0/1/0+1/5 |
Audio Chipset | Realtek ALC889 |
---|---|
Audio Channels | 8 Channels |
LAN Chipset | Marvell 88E8053 |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 2 |
---|---|
USB 1.1/2.0 | 6 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394a |
S/PDIF Out | 1 x Optical, 1 x Coaxial |
Audio Ports | 6 Ports |
Onboard USB | 3 x connectors for 6 additional external USB 2.0 ports |
---|---|
Onboard 1394 | 1 x 1394a |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 24 Pin |
Date First Available | January 19, 2009 |
---|
Pros: supports i7, ddr3 and the such. Lots of connectors for fans. The smart connectors that are in the package are awesome. And by far the most useful...easy to reset cmos (just hit power and rest at the same time.)
Cons: Personally, within the 2 days I've had this board, the bios has locked up more than 10 times. Now....thats just horrible. I also just tried out the Auto Boost System that was included with it.... It ended up screwing up my whole entire bios and prevented me from accessing it. The only way to fix it was to reset the bios and re-input my settings.
Overall Review: If you looking for a more stable board, you might wanna check something else out. But don't get me wrong, this board works and is VERY flexible, it's just a pain.
