Brand | BIOSTAR |
---|---|
Model | H61MGC |
CPU Socket Type | LGA 1155 |
---|---|
CPU Type | Celeron / Core i3 / Core i5 / Core i7 / Intel Core 2nd gen (LGA 1155) / Intel Core 3rd Gen (LGA 1155) / Pentium / Xeon (LGA1155) |
Chipset | Intel H61 |
---|
Onboard Video Chipset | Supported only by CPU with integrated graphic |
---|
Number of Memory Slots | 2x240pin |
---|---|
Memory Standard | DDR3 1600/1333/1066 |
Maximum Memory Supported | 16GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
---|---|
PCI Express x1 | 2 x PCI Express x1 |
Audio Chipset | VIA VT1708B |
---|---|
Audio Channels | 6 Channels |
LAN Chipset | Realtek 8111E |
---|---|
Max LAN Speed | 1Gbps |
Back I/O Ports | 2 x PS/2 / 4 x USB 2.0/1.1 |
---|---|
PS/2 | 2 |
Video Ports | D-Sub + DVI |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 4 x USB 2.0 |
---|---|
Other Connectors | 1 x Printer Header 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header |
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 8.9" x 6.89" |
Power Pin | 24 Pin |
Features | Socket LGA 1155 Supported the Intel 2nd generation Core i7/ i5/ i3 processors in the 1155 package Supported 2 DIMM of DDR3 1333/1066MHz Supports BIO-Remote 2 Technology Supports Charger Booster Technology |
---|
Date First Available | April 09, 2020 |
---|
