JetWay JXBLUE-78GA3L-LF AM3/AM2+/AM2 AMD 780G HDMI ATX AMD Motherboard

(10) Write a Review
  • AMD 780G
  • Phenom II / Phenom / Athlon II / Athlon64 /Sempron
  • DDR3 1333 / DDR2 1066
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (10)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the JETWAY JXBLUE-78GA3L-LF

Model
Brand JetWay
Model JXBLUE-78GA3L-LF
Supported CPU
CPU Socket Type AM3/AM2+/AM2
CPU Type Phenom II / Phenom / Athlon II / Athlon64 /Sempron
FSB 2600 MHz
Chipsets
Chipset AMD 780G
South Bridge AMD SB700
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR3 1333 / DDR2 1066
Maximum Memory Supported 4GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 1 * PCI Express x16 slot by 16-lane
1 * PCI Express x16 slot by 4-lane
PCI Express x1 1 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
PATA 1 x ATA133 2 Dev. Max
SATA RAID 0/1/10/JBOD
Onboard Video
Onboard Video Chipset ATI Radeon HD 3200
Onboard Audio
Audio Chipset Realtek ALC662
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Realtek 8111DL
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x D-Sub / 1 x DVI / 1 x HDMI / 2 x PS/2 / 3 x Audio Jacks / 4 x USB 2.0/1.1
PS/2 2
Video Ports D-Sub + DVI
HDMI 1 x HDMI
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Physical Spec
Form Factor ATX
Dimensions (W x L) 12" x 8.5"
Power Pin 24 Pin
Features
Features Integrated ATI Radeon HD 3200(For Microsoft DX 10)
Onboard DDR2 64MB sideport memory
Support G.P.I Technology
1 * WI-FI header, Support WI-FI Technology
Additional Information
First Listed on Newegg March 19, 2010
