Brand | Foxconn |
---|---|
Model | G45M-S |
CPU Socket Type | LGA 775 |
---|---|
CPU Type | Core 2 Quad / Core 2 Extreme / Core 2 Duo |
FSB | 1600(O.C)/1333MHz |
Chipset | Intel G45 |
---|---|
South Bridge | Intel ICH10R |
Onboard Video Chipset | Intel GMA X4500HD |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR2 1066(O.C.)/800 |
Maximum Memory Supported | 16GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
SATA RAID | 0/1/5/10 |
---|
Audio Chipset | Realtek ALC888-GR |
---|---|
Audio Channels | 8 Channels |
LAN Chipset | Realtek RTL8111B-VC-GR |
---|---|
Max LAN Speed | 1Gbps |
Back I/O Ports | 1 x HDMI / 2 x PS/2 / 4 x USB 2.0/1.1 |
---|---|
PS/2 | 2 |
Video Ports | D-Sub + Display Port |
HDMI | 1 x HDMI |
USB 1.1/2.0 | 4 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394a |
Audio Ports | 6 Ports |
Onboard USB | 4 x USB 2.0 headers support additional 8 ports |
---|---|
Onboard 1394 | 1 x 1394a |
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 9.6" |
Power Pin | 24 Pin |
Windows Vista | Certified for Windows Vista |
---|
Date First Available | November 28, 2008 |
---|
