EVGA 132-YW-E180-A1 LGA 775 NVIDIA nForce 790i SLI ATX Intel Motherboard

OUT OF STOCK.
  • NVIDIA nForce 790i SLI
  • Core 2 Quad / Core 2 Extreme / Core 2 Duo
  • DDR3 2000
Specs
Reviews

Learn more about the EVGA 132-YW-E180-A1

Model
Brand EVGA
Model 132-YW-E180-A1
Supported CPU
CPU Socket Type LGA 775
CPU Type Core 2 Quad / Core 2 Extreme / Core 2 Duo
FSB 1600/1333 MHz
Chipsets
Chipset NVIDIA nForce 790i SLI
Onboard Video
Onboard Video Chipset None
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR3 2000
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 3 x PCI Express 2.0 x16
PCI Express x1 2 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
PATA 1 x ATA100 2 Dev. Max
SATA 3Gb/s 9 x SATA 3Gb/s
SATA RAID NV RAID 0/1/0+1/5 JBOD
Onboard Audio
Audio Chipset Azalia (HDA)
Audio Channels 8 Channels
Onboard LAN
Max LAN Speed Dual 10/100/1000Mbps
Rear Panel Ports
PS/2 2
USB 1.1/2.0 6 x USB 2.0
IEEE 1394 1 x IEEE 1394a
eSATA 1 x eSATA 3Gb/s
S/PDIF Out 1 x Optical, 1 x Coaxial
Audio Ports 6 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Onboard 1394 1 x 1394a
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 24 Pin
Additional Information
Date First Available October 06, 2008

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
