Brand | EVGA |
---|---|
Model | 141-BL-E757-TR |
CPU Socket Type | LGA 1366 |
---|---|
CPU Type | Core i7 (LGA1366) |
FSB | QPI 6.4GT/S |
Chipset | Intel X58 |
---|---|
South Bridge | Intel ICH10R |
Onboard Video Chipset | None |
---|
Number of Memory Slots | 6x240pin |
---|---|
Memory Standard | DDR3 1600 |
Maximum Memory Supported | 24GB |
Channel Supported | Triple Channel |
PCI Express 2.0 x16 | 4 (@ x16/x8/x4/x8) |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 1 x PCI Slot |
SATA 3Gb/s | 6 x SATA 3Gb/s |
---|---|
SATA RAID | 0/1/0+1/5/JBOD |
Audio Channels | 8 Channels |
---|
Max LAN Speed | 10/100/1000Mbps |
---|
PS/2 | 1 |
---|---|
USB 1.1/2.0 | 8 x USB 2.0 |
S/PDIF Out | 1 x Optical, 1 x Coaxial |
Audio Ports | 6 Ports |
Onboard USB | 4 x USB 2.0 |
---|---|
Onboard 1394 | 2 x 1394a |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 24 Pin |
Features | Enthusiast Layout supporting 2-Way, 3-Way, and 3-Way SLI w/ PhysX EVGA Vdroop control: Stabilizes voltage and ensures the maximum stability when overclocking. Onboard Clear CMOS, Power and reset buttons with built in power and hdd activity led indicators. EVGA E-LEET Tuning Utility gives you quick access to overclocking controls without going into Bios. Onboard Debug LED shows CPU temperature. |
---|
Date First Available | June 03, 2009 |
---|
Pros: Very well laid out board. The sata connectors aren't covered by the GPU(s). The CPU power plug lies closer to the PSU so it's not as far a reach as some other boards. 6 dimm triple channel slots, 8 i/o sata connectors, 2 yr warranty, well built/sturdy i/o panel, 2 way & 3 way SLI bridge, OC for dummies setting, gig Ethernet, cmos clear switch. I love ths board. Quality is much better than an MSI i7 SLI mobo I purchased and returned.
Cons: No really a con, but no mobo standoffs if your case doesn't come with them. Some manufacturers do, some don't. The 6 dimm slots are a little close together.
Overall Review: Great customer support from EVGA, replaced 2 missing sata cables w/ out blinking an eye and also registered my board for me- have serial # ready. 2 YEAR WARRATY. CS was very friendly and helpful, SPOKE ENGLISH!! The OC for dummies setting, OC's your system and adjusts all the necessary system settings for you. OC'd my Intel 920 from 2.67 to over 3.0 and was stable with no high temps. Sweet board. i7 920, 6Gig GGsill, Radeon 4870, stock cooler, 700 watt PSU SLI- modular, CM690 case, 4 -120 fans.
