EVGA 141-BL-E757-RX LGA 1366 Intel X58 ATX X58 SLI LE Intel Motherboard
REFURBISHED Product Type
- Intel X58
- Core i7 (LGA1366)
- DDR3 1600
Specs
Reviews (19)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the EVGA 141-BL-E757-RX
| Brand | EVGA |
|---|---|
| Model | 141-BL-E757-RX |
| CPU Socket Type | LGA 1366 |
|---|---|
| CPU Type | Core i7 (LGA1366) |
| Chipset | Intel X58 |
|---|---|
| South Bridge | Intel ICH10R |
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 6x240pin |
|---|---|
| Memory Standard | DDR3 1600 |
| Maximum Memory Supported | 24GB |
| Channel Supported | Triple Channel |
| PCI Express 2.0 x16 | 4 (@ x16/x8/x4/x8) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 1 x PCI Slot |
| SATA RAID | 0/1/0+1/5/JBOD |
|---|
| Audio Channels | 8 Channels |
|---|
| Max LAN Speed | 1Gbps |
|---|
| Back I/O Ports | 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x S/PDIF Coaxial Out / 8 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| USB 1.1/2.0 | 8 x USB 2.0 |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|---|
| Onboard 1394 | 2 x 1394a |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Enthusiast Layout supporting 2-Way, 3-Way, and 3-Way SLI w/ PhysX EVGA Vdroop control: Stabilizes voltage and ensures the maximum stability when overclocking. Onboard Clear CMOS, Power and reset buttons with built in power and hdd activity led indicators. EVGA E-LEET Tuning Utility gives you quick access to overclocking controls without going into Bios. Onboard Debug LED shows CPU temperature. |
|---|
| First Listed on Newegg | February 14, 2011 |
|---|
