Brand | SilverStone |
---|---|
Model | SST-TX300 |
Type | TFX (Compatible with ATX12V v2.4) |
---|---|
Maximum Power | 300 W |
Fans | 1 x Silent Running 80mm Fan with 18 dBA Minimum |
PFC | Active |
+12V Rails | 2 |
PCI-Express Connector | 1 x 6-Pin |
SATA Power Connector | 4 |
Max PSU Length | 175 mm |
Efficiency | 82% - 85% at 20% - 100% loading |
Energy-Efficient | 80 PLUS BRONZE Certified |
Over Voltage Protection | Yes |
Input Voltage | 90 - 264 V |
Input Frequency Range | 47 - 63 Hz |
Output | +3.3V@15A, +5V@16A, +12V1@14A, +12V2@15A, [email protected], [email protected] |
MTBF | 100,000 hours |
Connectors | 1 x 24 / 20-Pin motherboard connector (350mm) 1 x 8 / 4-Pin EPS / ATX 12V connector (450mm) 1 x 6-Pin PCIE connector (350mm) 4 x SATA connector ("350mm / 150mm" x 2) 2 x 4-Pin Peripheral connector (350mm / 150mm) 1 x 4-Pin Floppy adapter connector (350mm / 150mm / 150mm) |
Features | Support standard TFX form factor 300W continuous power output at 40 Degree C operating temperature rated for 24/7 operation High efficiency with 80 PLUS Bronze certification Silent running 80mm fan with 18 dBA minimum Single PCI-E 6pin connectors support Active PFC Over Power Protection / Over Voltage Protection / Short Circuit Protection |
---|
Dimensions | 2.56" x 3.35" x 6.89" |
---|---|
Weight | 2.20 lbs. |
Date First Available | December 31, 2018 |
---|
