Specifications: Duplicate or dock a SATA SSD/HDD with fast performance - USB 3.1 (10Gbps) standalone duplicator dock for 2.5" & 3.5" SSD/HDD drives - HDD cloner with fast-speed SSD duplication up to 28GB/min - 2.5in and 3.5in hard drive duplicator and drive dock - Works with both USB-C and USB-A enabled devices w/ two cables included - Dual-bay duplicator dock featuring toaster-style design with drive doors and drive eject buttons - Compatible with Thunderbolt 3 USB-C port - Supports SATA I/I/III (up to 6Gbps)
Specifications: Interface: USB 3.0 & eSATA
Number of Drives: 2
Drive Size: 2.5in & 3.5in
Drive Type: SATA
Drive Installation: Removable
Chipset ID: JMicron - JMS562
Drive Connectors: 2 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors:
1 - eSATA (7 pin; Data) Female
1 - USB 3.0 B (9 pin; SuperSpeed) Female
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Type and Rate: SATA III (6 Gbps)
Max Drive Capacity: Currently tested with up to 4TB 7200 RPM 3.5" hard drives per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB total)
Insertion Rating: 15,000 Cycles
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III
Specifications: Host Interface: 7 pin SATA x 4
Drive Fit: 2.5" SATA I / II / III SSD or hard drive x 4
Drive Bay: Single 5.25" half height device bay
Transfer Rate: Up to 6 Gb / sec. (depending on hard drive speed)
Insert& Extract connection Via: Direct SATA hard drive connection
Structure: SECC
Device Power: Single 4 pin Molex power
Drive Cooling:
Dual 40mm rear cooling fan + fan power switch
Metal heat dispersion
Power Indicator: Solid Green LED
HDD Access Indicator: Flashing Amber LED
Dimension (L x W x H): 6.70" x 5.75" x 1.63"
Weight: 1.77 lbs.
Specifications: RoHS Compliance: Yes
Standard Drive Bays:
1 x 3.5" Hotswap
1 x 5.25" Drives
Hotswap HDD Type: 2.5" & 3.5" SAS I/II/III & SATA I/II/III
Indicators: Power and HDD activity
Material of Handle: Aluminum
Material of Main Chassis: Aluminum Design
Cooling Fan: 1 x 80mm
Dimensions: 1.65" x 5.75" x 7.32"
Specifications: Drive Connectors: 1 - M.2 (NGFF) Receptacle
Host Connectors: 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Maximum Data Transfer Rate: 6 Gbps
Type and Rate: SATA III (6 Gbps)
Specifications: Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in & 3.5in
Interface : USB 3.1 Gen 2
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 6TB
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 1 - Power and Activity
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 110 ~ 240 AC
Output Current: 2.0 A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
