Specifications: Interfaces:
Telephone Interfaces Two (2) FXS ports
Network Interfaces One (1) 10/100 Mbps auto-sensing ethernet ports (RJ45)
LED Indicators POWER, INTERNET, PHONE1, PHONE2
Factory Reset Button Yes
Voice, Fax, Modem:
Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward,
hold, do not disturb, 3-way conference
Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD / CNG), G.723.1, G.729A/B, G.726, iLBC,
OPUS, dynamic jitter buffer, advanced line echo cancellation
Fax Over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax
Pass-through
Short / Long Haul Ring Load 2 REN: Up to 1 km on 24 AWG
Caller ID Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
Disconnect Methods Busy Tone, Polarity Reversal / Wink, Loop Current
Signaling:
Network Protocols...
Specifications: Interfaces/Ports
PoE (RJ-45) Port:
No
USB:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
Wall Mountable
Desktop
Height:
3.9"
Width:
3.9"
Depth:
1"
Weight (Approximate):
4.70 oz
Features: Interfaces/Ports
Number of Network (RJ-45) Ports:
2
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Specifications: Pro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume dial
Replaceable tip
3.5 mm earphone jack
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
