Specifications: Approvals: CE, RoHS2, WEEE, UL
Connectors : (1) screw lock barrel power connector, (1) USB mini for power and FW upgrades; Input: (3) component video (one is used for composite), (2) 3.5-mm L/R audio, (1) SPDIF audio; Output: (1) HDMI video
Humidity 10% tp 90%, non-condensing
Maximum Altitude: 10,000 feet
Operating Temperature: 32º to 122º F (0 to 50ºC)
Power Source: wallmount style power supply, USB mini (not included); Input: 100–24- VAC, 50/60 Hz, 1.5 Amp; Output: 5 VDC 2A barrel plug
Storage Temperature: -40º to 158ºF (-40 to 70ºC)
User Controls : (3) push buttons
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
