| Brand | NVIDIA |
|---|---|
| Model | BlueField-3 E-Series - 16 Arm-Cores - 505 MHz/2000MHz |
| Part Number | 900-9D3C6-00CV-DA0 |
| Speed | DATA RATE InfiniBand: NDR200/HDR/HDR100/EDR/FDR/SDR Ethernet (Default Speed): 200/100/50/25/10 Gb/s |
|---|---|
| Connectors | Networking Connector: Dual-port QSFP112 (copper and optical) |
| Interface | PCI Express Interface: - Gen 5.0 SERDES @ 32.0GT/s, 16 lanes (4.0, 3.0, 2.0 and 1.1 compatible) Optional: Additional PCIe x16 Gen 5.0 @ SERDES 32GT/s through the PCIe auxiliary passive card and Cabline SA-II Plus harnesses. On-Board Memory: - Dual-channel with 20 DDR5 + ECC (128bit + 16bit ECC) for a total of 48GB @ 5200MT/s - 40GB pSLC eMMC memory + 128GB SSD |
| Features | PROTOCOL SUPPORT InfiniBand: IBTA v1.5a Auto-Negotiation: NDR200 ( 2 lanes x 100Gb/s per lane ) port, HDR (50Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR (14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane). Ethernet: 200GAUI-4 C2M, 200GAUI-2 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M , XLPPI, SFI |
|---|
| First Listed on Newegg | February 18, 2026 |
|---|
