Specifications: Audio: Yes
Chipset ID: MCT Trigger
Memory: 64MB DDRII SDRAM
Output Signal: HDMI
Ports: 2
Audio Specifications: 2-channel stereo
Maximum Digital Resolutions: 4K x 2K @ 30 Hz
Supported Resolutions
Output 1: 3840 x 2160, 2048 x 1152, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
Output 2: 2048 x 1152, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
**All resolutions support 16 and 32 bit color
Wide Screen Supported: Yes
Connector A: 1 x USB Type-A (9 pin) USB 3.0 Male Input
Microsoft WHQL Certified: Yes
OS Compatibility: Windows 10 (32/64), Windows 8 / 8.1 (32/64), Windows 7 (32/64)
Note: T...
Specifications: Host Interface: USB 3.0 Male Type-A Connector
Video Interface: 2 x HDMI Female Connector (HDMI Audio output simultaneously)
Max Resolution: 3840 x 2160 @ 30 Hz; 2048 x 1152 @ 60 Hz
Power Mode: Bus-powered
Power Consumption: = 400mA
Housing Material: Aluminum
Part Number: Input: 1 x USB 3.0 Cable1 x HDMI1 x VGA2 x USB 3.01 x RJ45 Gigabit EthernetCombo: 1 x SD Card Reader,1 x Micro SD Card Reader
Type: USB to HDMI Adapters
Color: Black
Features: Upstream USB3.0 foldable extension cable designed for Mini Dock handy travelling
Built in HDMI port maximum resolution up to 2560x1600 and VGA port reach at 1080p
Two USB-A ports extended USB3.0 (5Gbps) data transferring, and USB2.0 compliance
Gigabit Ethernet with devices wake up function
Combo built in USB3.0 SD and TF / Micro SD
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
