Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Maximum Power Delivery Support: 60 W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.9 to 10.12
Chrome OS
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI, VGA
Chipset ID: ITE - IT6222
Audio Specifications: HDMI output: 5.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz (VGA)
Maximum Digital Resolutions: 3840 x 2160 @ 30Hz (HDMI)
Supported Resolutions:
Maximum HDMI output:3840 x 2160 @ 30Hz
Maximum VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI / DVI-D / VGA / Mini-DisplayPort
Chipset ID:
Parade - PS176
VIA/VLI - VL102
ITE -IT6516
Audio Specifications: HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz
Maximum Digital Resolutions:
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI)
4096 X 2160 @ 60Hz (mDP)
Supported Resolutions:
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz
Maximum mDP output: 4096 X 2160 @ 60Hz
Maximum DVI and VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0 / DisplayPort 1.2
Wide Screen Supported: Yes
Note: On...
Compatibility: Windows 10
Windows 8.1
macOS Sierra (10.12)
macOS High Sierra (10.13)
macOS Mojave (10.14)
macOS Catalina (10.15)
Chrome OS 69.x
Android OS 9.x
iPadOS
Ports Spec: 1 x HDMI
1 x DisplayPort
1 x VGA (15 pin, High Density D-Sub)
1 x Ethernet Gigabit
1 x USB 3.1 USB Type-C (10 pin, Gen 2, 10 Gbps)
2 x USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps)
Support - Compact Flash: CF (Compact Flash I/II Card)
Support - SD: SD/MMC (Secure Digital/Multimedia Card)
SDHC (Secure Digital High Capacity)
SDXC (Secure Digital eXtended Capacity)
Micro-SD (Micro Secure Digital)
Micro-SDHC (Micro Secure Digital High Capacity)
Micro-SDXC (Secure Digital eXtended Capacity)
Slots: 1 x Micro-SD
1 x SD / MMC
1 x CF (Compact Flash I/II Card)
Specifications: Active Mini DisplayPort to DVI conversion
1x Male DisplayPort connector, 1x Male DVI connector
Compatible with Intel Thunderbolt devices that are capable of outputting a DisplayPort signal
Supports resolutions up to 1920x1200 (WUXGA) and HDTV resolutions up to 1080p
Plug-and-play Installation
Connector A:1 - Mini-DisplayPort (20 pin) Male
Connector B:1 - DVI-D (25 pin) Male
Maximum Digital Resolutions:2560x1600 (Dual link)
Supported Resolutions:2560x1600, 1920x1200, 1920x1080
Wide Screen Supported:Yes
