Specifications: Audio Specifications; DTS / Dolby Digital
Bandwidth: 18Gbps
Max Distance: 14 m / 45 ft
Video Revision: HDMI 2.0
Wide Screen Supported: Yes
Plug Type: USB Micro-B
Power Consumption (In Watts): <2.5
Power Source: Not Included (not required for standard applications)
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports : HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Supported Resolutions: 1280 x 720 (720p); 1920 x 1080 (1080p); 3840 x 2160 (4K)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Max. Distance (Between any 2 Units): 230 ft.
Maximum Distance with Booster: 400
Receiver/Transceiver Video Output: HDMI
Receiver - Number of Video Outputs: 1
Max Supported Color Depth: 36-bit Deep Color
HDR Support: Yes
3D Video Supported: Yes
Chroma Sub Sampling: 4:4:4
Maximum Signal Range (m): 70
HDCP Specification: 2.2
Driver Required: No
Recommended Category Cable: 26AWG STP Cat6/6a
EMI/RFI Line Noise Protection: Yes
DIN Mountable: No
Integrated/Removable Cable: No
Includ...
Max Extend Distance: Long range transmission:up to 20 km over a single-mode/Multi-mode LC fiber optic cable;
Specifications: 1080P 120Hz HDMI Extender HDMI Over Fiber Converter 4K@60HZ Video Optical Transceiver LC Single Mode 20km Multimode10G SFP
Video
Standards----------HDMI 2.0b; HDCP 2.2
Maximum pixel clock------600MHz
Maximum data rate-------18Gbps
Resolution ------3840X2160P@60Hz
Connector-----HDMI-A
Fiber type
Fiber interface--------------- LC Connector
Transmission distance--------0~20 km over single/multi-mode fiber
Fiber Type---------- ------------------ Single Mode
Wavelength--------------------1310nm 1510nm
Interface Bandwidth--------------18Gbps
Other
Power supply-----The power adapter: DC 5V/2A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------104*98*23mm
The warranty----...
