Memory Standard: 1R 3200 / 2933 / 2666 / 2133 (by JEDEC & POR)
Max overclocking frequency:
1DPC 1R Max speed up to 5200+
1DPC 2R Max speed up to 4800+
2DPC 1R Max speed up to 4400+
2DPC 2R Max speed up to 4000+
Specifications: Material: PCB Board. Protocol: M-Key and B+M Key. Input: M.2 SSD Slot, both M-Key and B+M Key M.2 SSD (NVMe, SATA Based). Output: USB 3.1 Type A. Dimension: 115*25*6 mm. Transfer Speed: 10Gbps/ 5Gbps (NOTE: If connect with usb 3.0 type a port, speed will be 5Gbps).
Specifications: 4Kn Support: Yes
Hot Swap Capability: Yes
Insertion Rating: 50,000 cycles
Max Drive Capacity: Currently tested with up to 10TB 7200 RPM hard drives
Maximum Data Transfer Rate : 6 Gbps
S.M.A.R.T. Support: Yes
TRIM Support: Yes
Type and Rate: USB 3.0 - 5 Gbit/s / SATA III (6 Gbps)
UASP Support: Yes
Specifications: PCIe - PCIe-X1,support PCIE X2,X4,X8,X16 Output interface - M.2 SATA SSD + SATA III OS - Windows10/8/7(32/64?)/ Vista(32/64?)/ XP/2003/2008/linux
Serial ATA (SATA): 6 x SATA 6Gb/s ports 1 2
1. The SATA5 port will be unavailable when installing M.2 SATA SSD into M2_3.
2. The SATA5 and SATA6 ports will be unavailable when installing M.2 PCIe SSD into M2_3.
