Specification: Ports In:
1 x HDMI Female
Ports Out:
Video Output: 1 x HDMI Female
Audio Output: 1 x TOSLINK (Optical) / 1 x RCA (Coaxial) / 2 x RCA (Stereo)
1 x DC Jack
Console Connectors (Flash ROM Upgrade): 1 x 4-conductor 3.5 mm Jack
1 x (Green) Power On LED
Switches
Mode Selection: Audio Channel - 1 x Slide Switch / HDMI Audio On/Off - 1 x Slide Switch
F/W Upgrade: 1 x semi-recessed pushbutton
Power: 5.3 VDc/150 mA
Power Consumption: 0.8 W - 3 BTU / hr
Dimension: 7.9" x 3.2" x 1"
Weight: 1 lbs.
Feature: Repeats HDMI input signal up to 15 meters
Extracts HDMI audio signal and outputs as additional audio source
Supports optical / coaxial digital audio and analog stereo audio
HDMI and HDCP compatible
Super Video Quality - up to 1920x1080 (1080p)
Firmware upgradable
CH2/CH5...
Specification: Connectors
Video In: 1 x DVI-D Female (White)
Audio In: 1 x Mini Stereo Jack (Green)
RS-232: 1 x DB 9 Female (Black)
Video Out: 2 x DVI-D Female (White)
Audio Out: 2 x Mini Stereo Jacks (Green)
Power: 1 x DC Jack
LEDs
Link -1 (Green)
Power - 1 (Green + Orange)
Resolution: Up to 2560 x 1600
Power Consumption: DC5.3V, 3.1W
Signal Range: 5 m (15 ft)
Environment
Operating Temp: 0-50 degree C
Storage Temp: -20-60 degree C
Humidity: 0-80% RH, Non-condensing
Dimension: 8.27" x 3.46" x 2.19"
Weight: 1.5 lbs.
Feature: Displays DVI audio/video to multiple DVI-compatible monitors or projectors
Superior video quality - up to 2560 x 1600 @ 60Hz and 1080p
Cascadable to 3 levels - provides up to 8 video signals
Audio enabled
Features RS-232 serial port for command controls
RS-232 Chain Contro...
Specification: Dimension: 5.58" x 4.06" x 1.23"
Weight: 0.93 lbs.
1 x HDMI Type A Female (Black)
1 x LC Simplex Connector (SFP)
1 x captive screw connector, 3 pole
1 x 3.5mm phone jack (Black)
1 x DC Jack (Black)
600 m with single mode (SM) fi ber
Wavelength: 1310/1550 nm for SM
Data rate: Single fi ber: 1080p/60Hz (24-bits,3.125G bps ), 720p/60Hz(24-bits,3.125G bps)
1 (Green) Power/Link LED
Power Consumption: DC5.3V, 2.4W
Metal Housing
Feature: Extends the transmission range of HDMI, IR and RS-232 signals using one fi ber optic cable
Very long distance transmission - up to 600m for VE882
HDMI (3D, Deep Color), HDCP compatible - signaling rates up to 3.125 Gbits
Superior video quality - up to 1080p@60Hz
FPGA design extends digital signals to longer distances
Uses one fiber optic cable...
Specification: Video Input Interface: HDMI (up to 4k@60fps)
Audio Input Interface: HDMI
Video Bypass: HDMI (up to 4k@60fps)
Video Resolution Input: 480p / 576p / 720p / 1080p / 2160p@60fps
Video Resolution Pass Through: 480p / 576p / 720p / 1080p / 2160p@60fps
Encode Resolution: Up to 1080p @ 60fps
Encode Format: Raw
Feature: The EVGA XR1 lite capture card allows you to capture every epic gameplay moment-Record at 1080p/60fps while you game at 4K/60fps. The new compact design and USB 3.0 are perfect for capturing gameplay or connect it to a DSLR camera for a high-quality webcam option.
System Requirements: Windows 7 and above with UVC (USB Video Class) v1.1 support
Mac OSX 10.13 and above with UVC support
Android Smartphone with UVC support*
System requirements:
CPU: Intel Core i3 2.8 GHz or higher
Memory: 4GB or more
One USB-A or USB-C 3.1 port
Stream software with UVC device support
Stream Software Support*:
Youtube, Facebook, and Twitch
OBS: https://obsproject.com
Xsplit: https://www.xsplit.com
*NOTE:
For latest Android phone that supports UVC format:
If after connecting to GUV301, the Android phone display output has fragmentation, glitch background or screen noise, the Android phone might be using bandwidth lower than USB3.0.
For such case, please download the firmware "GUV301_USB2.0_Smartphone Support" via Windows platform before connecting GUV301...
