Specifications: Drive Connectors: 1 - 29 pin SAS SFF-8482 Female Female
Host Connectors: 1 - 22 pin SATA DATA and Power Combo Male Male
1.70" x 7.10" x 5.70"
14.10 oz.
Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Specifications: Chipset ID: Xlinx - Spartan-6
Compatible Drive Types: SATA & USB Flash Drive
Fan(s): No
Number of Drives: 2
Maximum Data Transfer Rate: 6.6 GB per minute
Port Multiplier: No
Drive Connectors:
2 x 22 pin SATA Data + Power (7 + 15 pin) Receptacle
2 x USB Type-A (4 pin) USB 2.0
LED Indicators:
4 x Power/Activity
4 x Drive connection
4 x Drive error
Center Tip Polarity: Positive
Input Current: 1.4A
Input Voltage: 100 - 240 AC
Output Current: 5A
Output Voltage: 12 DC
Plug Type: M
Power Consumption (In Watts): 60
Power Source: AC Adapter Included
Enclosure Type: Steel
Specifications: Drive Connectors: 4 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors: 1 - USB Type-B (9 pin) USB 3.0 Female
Other Interface(s) : 1 - DB 9-pin Serial Male
Specifications: Duplication Modes:
System and File
All Partitions
Sector by Sector (Whole Drive)
Percentage Copy
Erase Modes:
Quick Erase
Secure Erase
1-Pass Overwrite
3-Pass Erase and Compare
3-Pass Overwrite
7-Pass Overwrite
Port Multiplier: No
Specifications: Drives Supported 2.5" HDD and SSD
CONNECTIONS:
Side A - Connector 1: MICRO-USB B (FEMALE)
Side B - Connector 1: 22 PIN SATA + POWER (FEMALE)
Connector Plating: Nickel
Contact Plating: Nickel
USB Specification: USB 3.1 Gen 1 (up to 5 Gbps)
Certifications: Tested to CE, FCC, ROHS
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Relative Humidity: 10% to 80%
