Specifications: Output
Output Connections:
(1) NEMA L14-30R
(2) NEMA L5-20R
Input
Nominal Input Voltage: 208V
Number of Power Cords: 1
Regulatory Approvals: CSA,UL 1778
Specifications: Temperature readings: Fahrenheit, Celsius
Temperature accuracy: 14°F to 158°F +/- 0.9°F; -10°C to 70°C +/- 0.5°C
Humidity accuracy: 10-90 RH ± 2%
Voltage: 12V (from RMCARD)
Input dry contact: 4
Connection port & cable: RJ45 Ethernet port x 2, 10 ft. cable, Daisy Chain x 8 Max
Specifications: Output
Output Power Capacity: 3200 Watts / 4000 VA
Max Configurable Power: 3200 Watts / 4000 VA
Nominal Output Voltage:120V,208V
Output Voltage Note: Configurable for 120/208 or 120/240 output voltage
Output Voltage Distortion: Less than 5% at full load
Output Frequency (sync to mains): 47 - 63 Hz
Waveform Type: Sine wave
Output Connections: (1) Hard Wire 4-wire (2PH + N +G)
Input
Nominal Input Voltage: 200V,208V
Input Frequency: 45 - 65 Hz (auto sensing)
Input voltage range for main operations: 155 - 276V
Other Input Voltages: 240V
Features: 72V / 60A Output
Fast Charge Technology with Built in Battery Charger
Daisy-chain Power Connections
Expandable up to 10 battery modules
Plug-n-Play DC connectors
2U Rack/Tower Convertible Form Factor
