Memory: 4 MB Flash, 8 MB SDRAM (standard)
64 MB Flash with real-time clock for a total of 68 MB (option)
Fonts Included: 16 resident expandable ZPL fonts
One resident scaleable ZPL font
5 resident expandable EPL2 fonts
Barcode Type: Linear Codabar
Code 11
Code 128
Code 39
Code 93
EAN-13
EAN-8
Industrial 2-of-5
Interleaved 2-of-5
Logmars
MSI
Plessey
Postnet
RSS-14 (limited, truncated, stacked)
Standard 2-of-5
UPC-A and UPC-E with EAN 2 or 5 digit extensions
UPC-E
UPC-A
EAN-14
Code 128 with subsets A/B/C
UCC/EAN-128
UPC-A and UPC-E with 2 or 5 digit extensions
EAN-8 and EAN-13 with 2 or 5 digit extensions
Japanese Postnet
MSI-3
German Post Code
2-dimensional Codablock
Code 49
Data Matrix
MaxiCode
MicroPDF417
PDF417
QR Code
RSS / GS1 DataBar family (12 barcodes)
Media Type: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
Media sizes supported: Maximum Label Length: 39.0 in./991 mm
Maximum Label and Media Width: 4.65 in./118 mm
Media Roll Size: 5.00 in./127 mm outer diameter Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters
Thickness: 0.003 in./0.08 mm - 0.012 in./0.305 mm (tear-off mode only)Maximum Label Length: 39.0 in./991 mm
Maximum Label and Media Width: 4.65 in./118 mm
Media Roll Size: 5.00 in./127 mm outer diameter Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional ...
Fonts Included: 16 resident expandable ZPL II bitmap fonts
One resident scalable ZPL font
Five resident expandable EPL2 bitmap fonts
Supports user-defined fonts and graphics - including customer logos
Barcode Type: Linear Codabar
Code 11
Code 128
Code 128 with subsets A/B/C
Code 39
Code 93
EAN-13
EAN-14
EAN-8
EAN-8 and EAN-13 with 2 or 5 digit extensions
German Post Code
Industrial 2-of-5
Interleaved 2-of-5
Japanese Postnet
Logmars
MSI
MSI-3
Postnet
RSS (reduced space symbology)
Standard 2-of-5
UCC/EAN-128
UPC and EAN 2 or 5 digit extensions
UPC-A
UPC-A and UPC-E with 2 or 5 digit extensions
UPC-A and UPC-E with EAN 2 or 5 digit extensions
UPC-E
2-dimensional Aztec
Codablock
Code 49
Data Matrix
MacroPDF417
MaxiCode
MicroPDF417
PDF417
QR Code
RSS ...
Fonts Included: 16 resident expandable ZPL II bitmap fonts.
Two resident scalable ZPL fonts.
Five resident expandable EPL2 fonts.
Native open-type font support.
Unicode compliant for multi-language, on demand thermal printing.
China units include SimSun simplified.
Chinese font.
64 MB user available non-volatile memory, 8 MB user available SDRAM.
Barcode Type: 1D Bar Codes:
Code 11, Code 39, Code 93, Code 128, IS BT128, UPC-A, UPC-E, EAN -8, EAN -13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI , Codabar and Planet Code
2D Bar Codes:
Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Fonts Included: Bitmap fonts A through H and GS symbols are expandable up to 10 times, height and width independent
Smooth scalable font (CG Triumvirate Bold Condensed) is expandable dot-by-dot, height and width independent
IBM Code Page 850 International Characters
Barcode Type: Linear Codabar
Code 11
Code 128 with subsets A/B/C and UCC case codes
Code 39
Code 93
EAN-13
EAN-8
ISBT-128
Industrial 2-of-5
Interleaved 2-of-5
Logmars
MSI
Planet Code
Plessey
Postnet
Standard 2-of-5
UPC and EAN 2 or 5 digit extensions
UPC-A
UPC-E
2-dimensiona lAztec
Codablock
Code 49
Data Matrix
MaxiCode
MicroPDF
PDF417
QR Code
QR Code (requires Asian version printer)
RSS / GS1 DataBar family (12 barcodes)
TLC 39
Ribbon Characteristics: Outside diameter: 3.20" / 81.30 mm on a 1.00" / 25.00 mm I.D. core
Ratio: 3:1 media-roll-to-ribbon ratio for ZT230
Width: 1.57" / 40.00 mm to 4.33" / 110.00 mm
Media Type: Continuous, die-cut, notch, black mark
Fonts Included: Fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width independently. However, fonts E and H (OCR-A and OCR-B) are not considered - in-spec" when expanded.
The scalable smooth font 0 (CG Triumvirate Bold Condensed) is expandable on a dot-by-dot basis, height and width independent, while maintaining smooth edges. Maximum character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G, and 0 through software control.
Barcode Type: Bar code modulus "X" dimension:
Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
Bar code ratios – 2:1, 7...
Fonts Included: Ten alphanumeric fonts from 2.5 to 23 point size, including OCR-A, OCR-B, CG Triumvirate smooth font from AGFA
Scalable Fonts: CG Triumvirate Bold Condensed, CG Triumvirate & CG Times with Cyrillic, Greek Arabic and Hebrew character
support
Barcode Type: Linear: Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5, Industrial 2 of 5, Std 2 of 5, Code 11, Code 93, Code 128, EAN-8, EAN-13, HIBC, Codabar, Plessey, UPC 2 and 5 digit addendums, Postnet, UCC/EAN Code 128, Telepen, Planetcode, FIM, USPS-4 State
2D Symbologies: MaxiCode, PDF417, USD-8, Datamatrix, QR Code, Codeablock, Code 16k, Aztec, TLC 39, Micro PDF417, GS1 Databar
