Additional Features: The Yealink A30-020-Zoom Room includes the MeetingBar A20 which features Smart Zoom Rooms Collaboration and ultra HD full-duplex voice. The A30-020-Zoom Room System has a powerful camera with a 133 ° angle and a 20MP lens. This bundle also includes 1 CTP18 touch-screen console that facilitates the control of the system. The CTP18 allows users to annotate on shared content for easy and efficient collaboration at your fingertips. The CTP18 is an Android-based, 8-inch device that runs on the Android operating system. The CTP18 can be used via PoE by connecting one cable that carries both data and power.
Additional Features: Ultra HD 4K @ 60fps
82° field of view
PTZ with 12x optical zoom
USB 3.0, HDMI and LAN
Sony CMOS sensor
Remote control with 10 camera presets for quick PTZ
PTZ Control: UVC, VISCA, Pelco-D/P, Onvif via RS232, RS422/RS485, LAN, IR Remote
IP Streaming: H.265, H264, RTSP, RTMP
Specification: 4K Ultra HD up to 3840 x 2160 @ 60fps
Image sensor: Sony CMOS sensor (1/2.8)
View angle: 82°
PTZ parameters:
Pan: : ±170°
Tilt: -30°/+90°
Zoom: 12x optical zoom
Presets: 255 (10 with remote)
Resolution: 8.51 MP, 16:9
Focus: Auto, manual, one push
Video output: HDMI, USB 3.0
Video codec LAN: H.265, H.264
Video codec USB 3.0: H.265, H.264, MJPEG, YUY2, MJPEG, NV12
Network protocol: RTSP, RTMP, ONVIF, GB/T28181, VISCA
Audio input: Double track 3.5mm linear input
Audio output: HDMI, LAN, USB 3.0
Input voltage: DC12V ±10%
Input current: <1A
Power: <12W...
Camera: Type: Digital video camera
Form Factor: Desktop
Camera Mechanical Design: Pan / tilt / zoom
Color Support: Color
Optical Zoom: 15
Digital Video Capture Resolution: 3840 x 2160
Video Modes: 1080p, 1440p, 4K, 720p, 900p
Interface Type: SuperSpeed USB 3.0
Features:
+50° / -90° tilt, 180° pan, 30 fps, 52.2° field of view (vertical), 82.1° field of view (horizontal), 90° diagonal field of view, Auto Focus, Motorized pan, Motorized tilt, Motorized zoom, Security lock slot (cable lock sold separately)
Specification: OS Required: Apple MacOS X 10.10 or later, Google Chrome OS, Microsoft Windows 7 / 8.1 / 10
Microphone: Type: Microphone
Microphone Operation Mode: Omni-directional
Form Factor: External
Frequency Response: 90 - 16000 hertz
Speakerphone: Type: Speaker(s)
Frequency Response: 300 - 10000 hertz
Total Harmonic Distortion (THD): 2.5...
Camera: Ultra-HD imaging system supports:
4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
1080p, 720p at 30fps and 60 fps
Additional Features: Studio-Quality Video
With an Ultra-HD imaging system, Rally delivers brilliantly sharp video, outstanding color, and exceptional optical accuracy at resolutions up to 4K. Logitech RightLight technology optimizes light balance to emphasize faces and render natural-looking skin tones, even in dim or backlit conditions.
Advanced Modular Audio
Crystal-clear audio is essential for world-class video conferencing, and Rally excels in delivering sound that's natural, crisp, and highly intelligible. Logitech RightSound® enhances voice clarity by suppressing background noise, auto-leveling voices, and focusing on active speakers. Exquisitely sensitive mic pods ensure that everyone in the meeting can be clearly heard while stand-alon...
Camera: Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical
Camera: Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical
