Additional Features: With a single USB connection, Logitech Swytch links a laptop to the room’s display, camera, and audio devices. Now, people can use meeting rooms with any video conferencing software, webinar platform, or streaming service.
Specification: SYSTEM REQUIREMENTS
- Meeting Room Equipment
Display: HDMI input
Conference Camera: USB conference camera with speakerphone
- Laptop Computers
USB 3.0 Port: Type A or Type C
USB Power Delivery: Up to 60 watts for compatible laptops that charge via USB Type C
Operating Systems with DisplayLink Plug and Display Drivers: Windows 10, macOS 10.15 and later, and Chrome OS 75 or later.
INSIDE THE BOX
Swytch Hub
Swytch Extender
Swytch Connector with 1.5m / 4.9ft USB Cable
100-240v Swytch Hub Power Supply
100-240v Swytch Extender Power Supply
5m / 16.4ft USB 3.0 Cabl...
Additional Features: The Yealink A30-020-Zoom Room includes the MeetingBar A20 which features Smart Zoom Rooms Collaboration and ultra HD full-duplex voice. The A30-020-Zoom Room System has a powerful camera with a 133 ° angle and a 20MP lens. This bundle also includes 1 CTP18 touch-screen console that facilitates the control of the system. The CTP18 allows users to annotate on shared content for easy and efficient collaboration at your fingertips. The CTP18 is an Android-based, 8-inch device that runs on the Android operating system. The CTP18 can be used via PoE by connecting one cable that carries both data and power.
Additional Features: Logitech Swytch is a laptop link for video conferencing in meeting rooms, linking a Windows 10 laptop, MacBook, or Chromebook to the conference camera and display with a single USB Type A or C connection.
In rooms with or without a dedicated computer - including BYOM rooms, Microsoft Teams Rooms, and Zoom Rooms - Swytch adds support for meetings on any service. Simply connect Swytch to a laptop via USB and launch the desired application. Swytch delivers broadcast-quality video at up to 4K resolution, and connects the laptop to the room's display.
Device management capabilities via Logitech Sync make it easy for IT to monitor and manage Swytch together with other meeting room devices, including Logitech MeetUp, Rally, and Tap.
With a one-cable laptop link to a meeting room's AV devices, Logitech Swytch makes every room ready for any meeting....
Additional Features: Key Features:
1 x 100Mbps RJ45 port (IEEE 802.3af, full-duplex)
1 x USB 2.0 Type A
1 x USB 2.0 Type C (with DP video input)
1 x HDMI video input
Presentation resolution: up to 4Kp15*
Physical Features
Compatible OS: Windows 7/8.1/10, macOS 10.6 or higher
Compatible applications: most PC applications, as the PC audio & video device
Digital Video Capture Resolution: Camera Type: Single-lens
Video Standards: H.264 AVC; H.264 High Profile; H.265; H.239
People Video Resolution: 4K, 30 fps (TX and RX) from 2048 Kbps; 1080p, 60 fps from 1740 Kbps; 1080p, 30 fps from 1024 Kbps; 720p, 60 fps from 832 Kbps; 720p, 30 fps from 512 Kbps
Content Video Resolution (Input): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); UXGA (1600 x 1200); SXGA (1280 x 1024); WXGA (1280 x 768); HD (1280 x 720); XGA (1024 x 768); SVGA (800 x 600)
Content Video Resolution (Output): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); SXGA+ (1400 x 1050); SXGA (1280 x 1024); HD (1280 x 720); XGA (1024 x 768)
Specification: Ports: 1 HDMI-in 2.0 (video and audio); 2 HDMI-out 2.0 (video); 1 USB Type-C® 5Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 RJ-45; 1 l...
Camera: Camera range (imperial): Up to 20 ft
Camera range (metric): Up to 6.1 m
Camera resolution: 2160p, 4K UHD (3840 x 2160)
Camera type: Single-lens
Digital Video Capture Resolution: Content video resolution (input): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); UXGA
(1600 x 1200); SXGA (1280 x 1024); WXGA (1280 x 768); HD (1280 x 720); XGA (1024 x 768); SVGA (800 x 600)
Content video resolution (output): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); SXGA+
(1400 x 1050); SXGA (1280 x 1024); HD (1280 x 720); XGA (1024 x 768)
Diagonal field of view (dFoV): 110°
Horizontal field of view (hFoV): 95°
People video resolution: 4K, 30 fps (TX and RX) from 2048 Kbps; 1080p, 60 fps from 1740 Kbps; 1080p, 30 fps from 1024 Kbps; 720p, 60 fps from 832 Kbps; 720p, 30 fps from 512 Kbps
