Specifications: Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
Device Interface
1 x Gigabit PoE++ in port
1 x Gigabit PoE+ out port
1 x Gigabit 24/48V DC passive PoE out port
LED indicators
Wall mount
IP67 housing
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
Gigabit: 2000Mbps (full duplex)
Performance
RAM buffer: 1Mb
MAC Address Table: 2K entries
Jumbo Frame: 9KB
DIP Switch
Adjust 24/48V DC passive voltage (default 48V DC)
Interface: 1 x 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Standards: IEEE 802.3 10BASE-T, IEEE 802.3ab 1000BASE-T, IEEE 802.3u 100BASE-TX and IEEE 802.3X Full Duplex
Connectors: 1 - USB 3.0 A (9 pin; SuperSpeed) Male
1 - RJ-45 Female
2 - USB 3.0 A (9 pin; SuperSpeed) Female
Temperature: Operating Temperature:0 degree C to 70 degree C (32 degree F to 158 degree F)
Storage Temperature: -10 degree C to 55 degree C (14 degree F to 131 degree F)
Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.]
Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.]
Standards: IEEE 802.3
Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes
Status LEDs:
PWR (Power): (below RJ-45)
ON = Lit for normal operation
FX-Link/Act (Fiber Link/Activity):
(Upper Left on RJ-45)
ON = Link; Flashing = Activity
TX-Link/Act (Copper Link/Activity):
(Upper Right on RJ-45)
ON = Link; Flashing = Activity
Power
Consumption: 3.15 Watts
Sources: Unit accepts 5 VDC to 28 VDC
Wall Mount AC adapter: 12 VDC 400mA
Environment
Storage: -15 to +65 °C
Operating: 0°C to 50°C
Altitude: 0 – 10,000 feet
Humidity: 5% to 95% (non-condensing)
Compliance
Safety: Wall Mount Power Supply, UL Listed,
C-UL Listed (Canada)
FCC Class A, CISPR22/EN55022...
Specifications: Compatible OEM: Industry Standard
Connector Types: RJ-45 & SFP
Data Rate: 1Gbs
Unmanaged
Media Conversion Type: Copper to MMF or SMF
Media Type: MMF or SMF
POE: No
Power Supply: AC/DC Power Adapter - 5V DC Input
Product Shipping Dimension(HxWxD): 4.0 in. x 3.0 in. x 1.0 in.
